Equip 19"-55" Push-In Pop-Out TV Wall Mount Bracket

Roll over image to zoom inClick to Open expanded view

Equip 19"-55" Push-In Pop-Out TV Wall Mount Bracket

Name: Equip 19"-55" Push-In Pop-Out TV Wall Mount Bracket
Brand: Equip
SKU: 650325

SKU: 650325

Equip 19"-55" Push-In Pop-Out TV Wall Mount Bracket, 50 kg, 48.3 cm (19"), 139.7 cm (55"), 100 x 100 mm, 600 x 400 mm, 0 - 10°

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Equip

Warranty
2 Years

SKU
650325

EAN
4015867207956

Bullet points

Point
Built-in Cable management

Compatible with landscape and portrait mounting

Modular mount with unlimited video display configurations

Push-In Pop-Out for easy access and after service

Design

Certification
CE

Housing material
Steel

Product colour
Black

Ergonomics

Angle of rotation
180°

Cable management
Yes

Distance to the wall (max)
31 cm

Distance to the wall (min)
11 cm

Tilt angle range
0 - 10°

Logistics data

Harmonized System (HS) code
85299097

Master (outer) case gross weight
15.5 kg

Master (outer) case height
660 mm

Master (outer) case length
110 mm

Master (outer) case width
600 mm

Products per master (outer) case
1 pc(s)

Mounting

Maximum screen size
139.7 cm (55")

Maximum VESA mount
600 x 400 mm

Maximum weight capacity
50 kg

Minimum screen size
48.3 cm (19")

Minimum VESA mount
100 x 100 mm

Mounting type
Wall

Number of displays supported
1

Other features

Country of origin
China

Packaging content

Manual
Yes

Mounting kit
Yes

Packaging data

Package depth
110 mm

Package height
660 mm

Package type
Box

Package weight
15.5 kg

Package width
600 mm

Technical details

Compliance certificates
RoHS

Weight & dimensions

Depth
310 mm

Depth (max)
31 cm

Height
610 mm

Weight
14 kg

Width
545 mm

Description

Equip 19"-55" Push-In Pop-Out TV Wall Mount Bracket. Maximum weight capacity: 50 kg, Minimum screen size: 48.3 cm (19"), Maximum screen size: 139.7 cm (55"), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 600 x 400 mm. Tilt angle range: 0 - 10°. Product colour: Black

Maximum weight capacity: 50 kg Black
Maximum screen size: 139.7 cm (55")
Mounting type: Wall
Minimum VESA mount: 100 x 100 mm Maximum VESA mount: 600 x 400 mm
Cable management
Housing material: Steel
Compatible with landscape and portrait mounting
Push-In Pop-Out for easy access and after service
Modular mount with unlimited video display configurations
Built-in Cable management
