QNAP TVS-h1288X NAS Tower Ethernet LAN Black W-1250

Roll over image to zoom inClick to Open expanded view

QNAP TVS-h1288X NAS Tower Ethernet LAN Black W-1250

Name: QNAP TVS-h1288X NAS Tower Ethernet LAN Black W-1250
Brand: QNAP
SKU: TVS-H1288X-W1250-16G

SKU: TVS-H1288X-W1250-16G

QNAP TVS-h1288X, NAS, Tower, Intel® Xeon®, W-1250, Black

hypertec

Product manual (Download)

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
QNAP

Warranty
1 Year

Drive
Without Drives

SKU
TVS-H1288X-W1250-16G

EAN
4713213518410

Design

Built-in display
Yes

Cable lock slot
Yes

Cable lock slot type
Kensington

Chassis type
Tower

Cooling type
Active

Display type
LCD

Fan diameter
9.7 cm

Fan diameter 2
8 cm

LED indicators
HDD, LAN, SSD, System, USB

Number of fans
5 fan(s)

Product colour
Black

Logistics data

Harmonized System (HS) code
84714100

Memory

Flash memory
5000 MB

Internal memory type
DDR4

Maximum RAM supported
128 GB

Memory form factor
UDIMM

Memory Installed
16 GB

Memory slots
4

Network

Copper ethernet cabling technology
10GBASE-T

DHCP client
Yes

DHCP server
Yes

Dynamic DNS (DDNS)
Yes

Ethernet LAN
Yes

Ethernet LAN data rate supported (max)
10000 Mbit/s

Ethernet LAN data rates
10,100,1000,2500,10000 Mbit/s

iSCSI support
Yes

Jumbo frames support
Yes

Link aggregation
Yes

Load balancing system
Yes

Supported network protocols
IPv4, IPv6

Wake-on-LAN ready
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
-20 - 70 °C

Packaging content

Cables included
AC, LAN (RJ-45)

Drive tray key included
Yes

Number of screws
48

Power cables quantity
1

Quick installation guide
Yes

Performance

Access Control List (ACL)
Yes

Backup features
Cloud, USB drive, iSCSI LUN

Backup function
Yes

Browser supported
Apple Safari, Google Chrome, Internet Explorer, Mozilla Firefox

Built-in FTP server
Yes

Buzzer
Yes

Hot spare
Yes

Multilingual support
Yes

Noise level
26 dB

On/off switch
Yes

Reset button
Yes

S.M.A.R.T. support
Yes

Security algorithms
256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS

Snapshot
Yes

System log
Yes

Third-party support
Yes

Type
NAS

Ports & interfaces

Concurrent connections
10000

Ethernet LAN (RJ-45) ports
6

HDMI ports
1

HDMI version
1.4b

PCI Express x4 (Gen 3.x) slots
2

PCI Express x8 (Gen 3.x) slots
1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
2

USB port
Yes

Power

AC input voltage
100 - 240 V

Fan voltage
12 V

Power consumption (sleep)
85.216 W

Power consumption (typical)
97.492 W

Power supply location
Built-in

Power supply unit (PSU) capacity
550 W

Processor

CPU configuration (max)
1

Number of Cores
6

On-board graphics card model
Intel UHD Graphics P630

Processor
W-1250

Processor boost frequency
4.7 GHz

Processor cache
12 MB

Processor family
Intel® Xeon®

Processor frequency
3.3 GHz

Processor manufacturer
Intel

Processor threads
12

Processor special features

Embedded options available
No

Enhanced Intel SpeedStep Technology
Yes

Execute Disable Bit
Yes

Idle States
Yes

Intel 64
Yes

Intel Clear Video Technology
Yes

Intel Trusted Execution Technology
Yes

Intel Virtualization Technology (VT-x)
Yes

Intel Virtualization Technology for Directed I/O (VT-d)
Yes

Intel VT-x with Extended Page Tables (EPT)
Yes

Software

Linux operating systems supported
CentOS 7.0, SuSE Linux 12.0, SuSE Linux 12.3, SuSE Linux 15, Ubuntu 14.04, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10, Ubuntu 18.04 LTS, Ubuntu 20.04 LTS

Operating system installed
QuTS hero

Operating system version
h5.0.0

Other operating systems supported
IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11

Server operating systems supported
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Storage

Disk roaming
Yes

Hot-swap drive bays
Yes

Installed storage drive type
No

Number of M.2 (M & B) slots
2

Number of storage drives supported
12

Online RAID expansion
Yes

Online RAID migration
Yes

RAID levels
0, 1, 5, 6, 10, 50, 60, JBOD

RAID rebuild
Yes

RAID support
Yes

Storage drive sizes supported
2.5,3.5,M.2

Storage drives installed
No

Supported file systems
FAT32, HFS+, NTFS, ZFS, exFAT, ext3, ext4

Supported storage drive interfaces
M.2, Serial ATA II, Serial ATA III

Supported storage drive types
HDD & SSD

Weight & dimensions

Depth
319.8 mm

Height
234.6 mm

Package weight
14.9 kg

Weight
11.3 kg

Width
369.9 mm

Description

QNAP TVS-h1288X. Supported storage drive types: HDD & SSD, Supported storage drive interfaces: M.2, Serial ATA II, Serial ATA III, Storage drive sizes supported: 2.5,3.5,M.2. Processor family: Intel® Xeon®, Processor manufacturer: Intel, Processor model: W-1250. Internal memory: 16 GB, Internal memory type: DDR4, Maximum RAM supported: 128 GB. Ethernet LAN data rates: 10,100,1000,2500,10000 Mbit/s, Ethernet LAN data rate supported (max): 10000 Mbit/s, Copper ethernet cabling technology: 10GBASE-T. HDMI version: 1.4b

NAS Tower Black
QuTS hero h5.0.0
Number of storage drives supported: 12 HDD & SSD M.2, Serial ATA II, Serial ATA III
Intel® Xeon® W-1250 3.3 GHz Intel UHD Graphics P630
16 DDR4 Memory slots: 4 UDIMM
Ethernet LAN 10000 DHCP server Jumbo frames support iSCSI support Wake-on-LAN ready
Cooling type: Active LCD
Backup features: Cloud, USB drive, iSCSI LUN 550 W
Attain quad-port Thunderbolt™ 3 connectivity by installing two QXP-T32P expansion cards in the PCIe Gen 3 x4 slots
Two 10GBASE-T and four 2.5GbE LAN ports accelerate virtualization, intensive file access, large backup/restoration tasks, and media transfer
PCIe slots allow for installing 5/10/25/40GbE adapters, QM2 cards, or graphics cards to increase application performance
4K media playback and real-time transcoding; directly output videos to an HDMI display (up to 4K @30Hz)
Supports virtual machines and containerized apps, centralized storage, backup, sharing, disaster recovery, and storage expansion
Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud
