QNAP TVS-673e NAS Tower AMD Embedded R-Series SoC RX-421BD 4 GB DDR4 60 TB HDD QNAP Turbo System Black, Bronze

Roll over image to zoom inClick to Open expanded view

QNAP TVS-673e NAS Tower AMD Embedded R-Series SoC RX-421BD 4 GB DDR4 60 TB HDD QNAP Turbo System Black, Bronze

Name: QNAP TVS-673e NAS Tower AMD Embedded R-Series SoC RX-421BD 4 GB DDR4 60 TB HDD QNAP Turbo System Black, Bronze
Brand: QNAP
SKU: TVS-673E-4G/60TB-EXOS

SKU: TVS-673E-4G/60TB-EXOS

Log In to View Pricing

QNAP TVS-673e, NAS, Tower, AMD Embedded R-Series SoC, RX-421BD, 4 GB, DDR4

hypertec

Generated PDF (Download)

Add to compare

Product Properties

Manufacturer
QNAP

Warranty
2 Years

Drive
With drives

SKU
TVS-673E-4G/60TB-EXOS

EAN
5050914113568

Design

Built-in display
Yes

Built-in speaker(s)
Yes

Cable lock slot
Yes

Cable lock slot type
Kensington

Chassis type
Tower

Cooling type
Active

Display type
LCD

Fan diameter
9 cm

Fan diameter 2
6 cm

LED indicators
HDD, LAN, Status, USB

Number of built-in speakers
1

Number of fans
3 fan(s)

Product colour
Black, Bronze

Memory

Flash memory
512 MB

Internal memory type
DDR4

Maximum RAM supported
64 GB

Memory clock speed
2133 MHz

Memory form factor
SO-DIMM

Memory Installed
4 GB

Memory slots
4

Network

DHCP client
Yes

DHCP server
Yes

Dynamic DNS (DDNS)
Yes

Ethernet LAN
Yes

Ethernet LAN data rates
10,100,1000 Mbit/s

iSCSI support
Yes

Jumbo frames support
Yes

Link aggregation
Yes

Supported network protocols
CIFS/SMB, AFP (v3.3), FTP, FTPS, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP

Wake-on-LAN ready
Yes

Wi-Fi
No

WLAN adapter supported
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 40 °C

Packaging content

Cables included
AC, LAN (RJ-45)

Number of screws
20

Quick installation guide
Yes

Performance

Backup button
Yes

Backup features
Cloud, USB drive, iSCSI LUN

Backup function
Yes

Browser supported
Microsoft Internet Explorer 10+, Google Chrome, Apple Safari 7+, Mozilla Firefox

Built-in FTP server
Yes

Built-in iTunes server
Yes

Device class
Small & Medium Business

Hot spare
Yes

Management protocols
SNMP

Noise level
23 dB

Number of users
4096 user(s)

On/off switch
Yes

Remotely operated
Yes

Reset button
Yes

Security algorithms
256-bit AES, HTTPS, SSH

Share folder
512

Share folder access right management
Yes

Snapshot
Yes

System log
Yes

Third-party support
Yes

Type
NAS

Universal Plug and Play (UPnP)
Yes

USB copy function
Yes

Web-based management
Yes

Ports & interfaces

3.5 mm (1/8-inch) out
Yes

Ethernet LAN (RJ-45) ports
4

HDMI ports
2

HDMI version
1.4b

PCI Express x4 (Gen 3.x) slots
2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4

USB port
Yes

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Number of power supply units
1

Output current
3.5 A

Power supply location
Built-in

Power supply unit (PSU) capacity
250 W

Processor

Number of Cores
4

On-board graphics card model
AMD Radeon R7

Processor
RX-421BD

Processor boost frequency
3.4 GHz

Processor family
AMD Embedded R-Series SoC

Processor frequency
2.1 GHz

Software

Linux operating systems supported
Yes

Mac operating systems supported
Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion

Operating system installed
QNAP Turbo System

Operating system version
4.3

Server operating systems supported
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016

Storage

Hot-swap drive bays
Yes

Installed storage drive type
HDD

Number of M.2 (M & B) slots
2

Number of storage drives supported
6

Online RAID expansion
Yes

Online RAID migration
Yes

RAID levels
0, 1, 5+S, 5, 6, 6+HS, 10+HS, 10, JBOD

RAID support
Yes

Storage drive sizes supported
2.5,3.5,M.2

Storage drives installed
Yes

Supported file systems
FAT32, HFS+, exFAT, ext3, ext4

Supported storage drive interfaces
M.2, Serial ATA III

Supported storage drive types
HDD & SSD

Total installed storage capacity
60 TB

Weight & dimensions

Depth
279.6 mm

Height
188.2 mm

Width
264.3 mm

Description

QNAP TVS-673e. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Processor family: AMD Embedded R-Series SoC, Processor model: RX-421BD, Processor frequency: 2.1 GHz. Internal memory: 4 GB, Internal memory type: DDR4. Total installed storage capacity: 60 TB, Installed storage drive type: HDD. Operating system installed: QNAP Turbo System

Small & Medium Business NAS Tower Black, Bronze
QNAP Turbo System 4.3
Total installed storage capacity: 60 TB Number of storage drives supported: 6 HDD & SSD M.2, Serial ATA III
AMD Embedded R-Series SoC RX-421BD 2.1 GHz AMD Radeon R7
4 DDR4 2133 MHz Memory slots: 4 SO-DIMM
Ethernet LAN DHCP server Jumbo frames support iSCSI support Wake-on-LAN ready
Cooling type: Active LCD
Backup features: Cloud, USB drive, iSCSI LUN 250 W
