Trendnet TI-TPG80 network switch Managed Power over Ethernet (PoE) Black
Roll over image to zoom inClick to Open expanded view
Trendnet TI-TPG80 network switch Managed Power over Ethernet (PoE) Black
Trendnet TI-TPG80 network switch Managed Power over Ethernet (PoE) Black
Trendnet TI-TPG80 network switch Managed Power over Ethernet (PoE) Black

Trendnet TI-TPG80 network switch Managed Power over Ethernet (PoE) Black

SKU: TI-TPG80
Trendnet TI-TPG80, Managed, Power over Ethernet (PoE)
Specifications
More Information
PDF

Product Properties

  • Warranty
  • 2 Years
  • SKU
  • TI-TPG80
  • EAN
  • 0710931161410
  • Bullet points
  • Data transmission
  • Jumbo frames support
  • Yes
  • Design
  • Logistics data
  • Management features
  • Network
  • Operational conditions
  • Packaging data
  • Performance
  • Power
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Power over Ethernet (PoE) power per port
  • 30 W
  • Power over Ethernet plus (PoE+) ports quantity
  • 8
  • Total Power over Ethernet (PoE) budget
  • 200 W
  • Security
  • MAC address filtering
  • Yes
  • Weight & dimensions

Description

Trendnet TI-TPG80. Switch type: Managed. MAC address table: 11000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x. DC input voltage: 24 - 56 V. Power over Ethernet (PoE)
  • Managed
  • MAC address table: 11000 entries Switching capacity: 16 Gbit/s
  • Power over Ethernet (PoE)
  • 8 x M12 Gigabit PoE+ ports
  • PoE power budget: 200W@48V DC; 100W@24V DC
  • EN50155 compliant for rolling stock and railway applications
  • Hardened IP40 rated metal housing
  • 16Gbps switching capacity
  • Includes wall mount brackets
  • Operating temperature range of -40° – 75° C (-40° – 167° F)
  • Dual redundant power inputs with overload current protection
  • Alarm relay triggered by power failure
  • Power supply sold separately (models: TI-S24048)
  • M12 and M23 cables sold separately (models: TI-TCD02 / TI-TCD06 / TI-TCP02 / TI-TCR02)
