Trendnet TI-M12 gateway/controller 10, 100 Mbit/s
Roll over image to zoom inClick to Open expanded view
Trendnet TI-M12 gateway/controller 10, 100 Mbit/s
Trendnet TI-M12 gateway/controller 10, 100 Mbit/s
Trendnet TI-M12 gateway/controller 10, 100 Mbit/s
Trendnet TI-M12 gateway/controller 10, 100 Mbit/s
Trendnet TI-M12 gateway/controller 10, 100 Mbit/s
Trendnet TI-M12 gateway/controller 10, 100 Mbit/s

Trendnet TI-M12 gateway/controller 10, 100 Mbit/s

SKU: TI-M12
Trendnet TI-M12, Black, Metal, DIN-rail, IP30, FCC IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 IEC 61000-4-2 IEC 61000-4-4 IEC 61000-4-5, 521243 h
Specifications
More Information
PDF

Product Properties

  • Warranty
  • 2 Years
  • SKU
  • TI-M12
  • EAN
  • 0710931161656
  • Bullet points
  • Design
  • International Protection (IP) code
  • IP30
  • Features
  • Network
  • Flow control support
  • Yes
  • Operational conditions
  • Packaging content
  • Quick installation guide
  • Yes
  • Ports & interfaces
  • Ethernet LAN (RJ-45) ports
  • 2
  • Power
  • Protocols
  • Sustainability
  • Sustainability compliance
  • Yes
  • Technical details
  • Compliance certificates
  • CE
  • Weight & dimensions

Description

Trendnet TI-M12. Product colour: Black, Enclosure material: Metal, Mounting type: DIN-rail. Mean time between failures (MTBF): 521243 h. Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x. Serial interface type: RS-232. Power consumption (max): 3.84 W, Input voltage: 12 - 56 V
  • 10,100 Mbit/s
  • DIN-rail IP30
  • Enclosure material: Metal
  • Black
  • 1 x serial port, 2 x Fast Ethernet ports
  • Connect a RS-232/RS-422/RS-485 serial device, such as a modem, to a network
  • Supports DHCP, automatically obtain an IP address and query IP address through serial setting protocol
  • Configure via web management or telnet
  • Auto-MDI/MDIX, RJ45 port with 10/100Mbps
  • Serial port baud rate from 50bps to 921.6Kbps
  • Wide operation temperature range -40° - 75° C (-40° – 167° F)
  • IP30 rated metal housing
  • NDAA / TAA compliant (U.S. and Canada only)
