Synology RackStation RS822+ NAS Rack (1U) Ryzen Embedded V1500B 2 GB DDR4 1.92 TB SSD DiskStation Manager Black

Roll over image to zoom inClick to Open expanded view

Synology RackStation RS822+ NAS Rack (1U) Ryzen Embedded V1500B 2 GB DDR4 1.92 TB SSD DiskStation Manager Black

Name: Synology RackStation RS822+ NAS Rack (1U) Ryzen Embedded V1500B 2 GB DDR4 1.92 TB SSD DiskStation Manager Black
Brand: Synology
SKU: RS822+/1.92TB-SAT52

SKU: RS822+/1.92TB-SAT52

Log In to View Pricing

Synology RackStation RS822+, NAS, Rack (1U), Ryzen Embedded, V1500B, 2 GB, DDR4

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Synology

Warranty
3 Years

Drive
With drives

SKU
RS822+/1.92TB-SAT52

EAN
5050914192563

Bullet points

Design

Chassis type
Rack (1U)

Cooling type
Active

Drive bay locking
Yes

Fan diameter
4 cm

LED indicators
Alarm, HDD, Power, Status

Number of fans
3 fan(s)

Product colour
Black

Memory

ECC
Yes

Internal memory type
DDR4

Maximum RAM supported
32 GB

Memory form factor
SO-DIMM

Memory Installed
2 GB

Memory slots
2

Network

Ethernet LAN
Yes

Ethernet LAN data rates
1000 Mbit/s

iSCSI support
Yes

Link aggregation
Yes

Supported network protocols
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Wake-on-LAN ready
Yes

WLAN adapter supported
Yes

Operational conditions

Operating altitude
0 - 5000 m

Operating relative humidity (H-H)
8 - 80%

Operating temperature (T-T)
0 - 35 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
-20 - 60 °C

Other features

Compliance certificates
BSMI, CCC, CE, EAC, Federal Communications Commission (FCC), KC, RCM, RoHS, UKCA, VCCI

Packaging content

Cables included
AC

Power cables quantity
1

Performance

Access Control List (ACL)
Yes

Backup features
Cloud, iSCSI LUN

Backup function
Yes

Browser supported
Google Chrome, Firefox, Microsoft Edge, Safari

Built-in FTP server
Yes

Built-in iTunes server
Yes

Device class
Small & Medium Business

Hot spare
Yes

Multilingual support
Yes

Number of users
2048 user(s)

On/off switch
Yes

Reset button
Yes

Security algorithms
HTTPS, SSH, SSL/TLS

Share folder
SMB/AFP/NFS/FTP/WebDAV

Snapshot
Yes

System log
Yes

Third-party support
Yes

Type
NAS

Ports & interfaces

Concurrent connections
500

eSATA ports quantity
1

Ethernet LAN (RJ-45) ports
4

PCI Express x8 (Gen 3.x) slots
1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2

USB port
Yes

Power

AC input frequency
50/60 Hz

AC input voltage
100 - 240 V

Power consumption (HDD standby)
16.7 W

Power consumption (typical)
47.69 W

Power supply location
Built-in

Power supply unit (PSU) capacity
150 W

Processor

L2 cache
2 MB

L3 cache
4 MB

Number of Cores
4

Number of processors supported
1

Processor
V1500B

Processor family
Ryzen Embedded

Processor frequency
2.2 GHz

Processor generation
AMD Ryzen Embedded V1000 Series

Processor manufacturer
AMD

Processor threads
8

Software

Linux operating systems supported
Yes

Mac operating systems supported
Yes

Operating system installed
DiskStation Manager

Windows operating systems supported
Yes

Storage

Hot-swap drive bays
Yes

Installed storage drive type
SSD

Number of storage drives supported
4

Online RAID expansion
Yes

Online RAID migration
Yes

RAID levels
0, 1, 5, 6, 10, JBOD

RAID support
Yes

Storage drive sizes supported
2.5,3.5"

Storage drives installed
Yes

Supported file systems
BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4

Supported storage drive interfaces
Serial ATA II, Serial ATA III

Supported storage drive types
HDD & SSD

Total installed storage capacity
1.92 TB

Sustainability

Sustainability certificates
UL ECOLOGO

Sustainability compliance
Yes

Weight & dimensions

Depth
492.6 mm

Height
44 mm

Width
480 mm

Description

Synology RackStation RS822+. Type: NAS. Chassis type: Rack (1U). Device class: Small & Medium Business. Processor family: Ryzen Embedded, Processor model: V1500B, Processor frequency: 2.2 GHz. Internal memory: 2 GB, Internal memory type: DDR4. Total installed storage capacity: 1.92 TB, Installed storage drive type: SSD. Operating system installed: DiskStation Manager

Small & Medium Business NAS Rack (1U) Black
DiskStation Manager
Total installed storage capacity: 1.92 TB Number of storage drives supported: 4 HDD & SSD Serial ATA II, Serial ATA III
Ryzen Embedded V1500B 2.2 GHz
2 DDR4 Memory slots: 2 SO-DIMM ECC
Ethernet LAN iSCSI support Wake-on-LAN ready
Cooling type: Active
Backup features: Cloud, iSCSI LUN 150 W
2103/1074 MB/s sequential read/write throughput
Scale up to 8 drives with Synology Expansion Unit RX418
Built-in 4 x 1GbE ports with 10/25 GbE expansion option
Up to 32 GB DDR4 ECC
