Synology RackStation RS1619XS+ NAS Rack (1U) 8 GB DDR4 12 TB HDD Black

Roll over image to zoom inClick to Open expanded view

Synology RackStation RS1619XS+ NAS Rack (1U) 8 GB DDR4 12 TB HDD Black

Name: Synology RackStation RS1619XS+ NAS Rack (1U) 8 GB DDR4 12 TB HDD Black
Brand: Synology
SKU: RS1619XS+12TB-IW

SKU: RS1619XS+12TB-IW

Log In to View Pricing

Synology RackStation RS1619XS+, NAS, Rack (1U), 8 GB, DDR4, 12 TB, HDD

Add to compare

Product Properties

Manufacturer
Synology

Warranty
5 Years

SKU
RS1619XS+12TB-IW

EAN
5050914079147

Bullet points

Point
1,523 MB/s sequential reading, 162,097 iSCSI random read IOPS

8GB DDR4 UDIMM, up to 64GB

Quad-core up to 2.7GHz

Up to 16 drives with one RX1217/RX1217RP1

Design

Chassis type
Rack (1U)

Cooling type
Active

Fan diameter
4 cm

LED indicators
Yes

Number of fans
2 fan(s)

Product colour
Black

Memory

Internal memory type
DDR4

Maximum RAM supported
64 GB

Memory Installed
8 GB

Memory slots
4

Network

Ethernet LAN
Yes

Ethernet LAN data rates
10,100,1000 Mbit/s

iSCSI support
Yes

Link aggregation
Yes

Wake-on-LAN ready
Yes

Wi-Fi
No

Operational conditions

Operating altitude
0 - 5000 m

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
5 - 35 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
-20 - 60 °C

Other features

Compliance certificates
RoHS

Digital Living Network Alliance (DLNA) certified
Yes

Packaging content

Cables included
AC

Quick installation guide
Yes

Performance

Access Control List (ACL)
Yes

Backup features
Cloud, iSCSI LUN

Backup function
Yes

Device class
Small & Medium Business

Multilingual support
Yes

On/off switch
Yes

Reset button
Yes

S.M.A.R.T. support
Yes

Security algorithms
HTTPS, SSH, SSL/TLS

Type
NAS

Web-based management
Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports
4

Expansion ports quantity
1

PCI Express x8 (Gen 3.x) slots
1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2

USB port
Yes

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Number of power supply units
2

Power supply location
Built-in

Power supply unit (PSU) capacity
150 W

Processor

Processor frequency
2.2 GHz

Software

Mac operating systems supported
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave

Server operating systems supported
Windows Server 2016

Windows operating systems supported
Windows 10, Windows 7

Storage

Hot-swap drive bays
Yes

Installed storage drive type
HDD

Number of storage drives installed
4

Number of storage drives supported
4

RAID levels
0, 1, 5, 6, 10, JBOD

RAID support
Yes

Storage drive sizes supported
2.5,3.5"

Storage drives installed
Yes

Supported file systems
BTRFS, Fat, HFS+, NTFS, ext3, ext4

Supported storage drive interfaces
Serial ATA, Serial ATA II, Serial ATA III

Supported storage drive types
HDD & SSD

Total installed storage capacity
12 TB

Weight & dimensions

Depth
518.6 mm

Height
44 mm

Width
480 mm

Description

Synology RackStation RS1619XS+. Type: NAS. Chassis type: Rack (1U). Device class: Small & Medium Business. Processor frequency: 2.2 GHz. Internal memory: 8 GB, Internal memory type: DDR4. Total installed storage capacity: 12 TB, Installed storage drive type: HDD

Small & Medium Business NAS Rack (1U) Black
Total installed storage capacity: 12 TB Number of storage drives supported: 4 HDD & SSD Serial ATA, Serial ATA II, Serial ATA III
2.2 GHz
8 DDR4 Memory slots: 4
Ethernet LAN iSCSI support Wake-on-LAN ready
Cooling type: Active
Backup features: Cloud, iSCSI LUN 150 W
Quad-core up to 2.7GHz
8GB DDR4 UDIMM, up to 64GB
1,523 MB/s sequential reading, 162,097 iSCSI random read IOPS
Up to 16 drives with one RX1217/RX1217RP1
