Synology RackStation RS422+ NAS/storage server Rack (1U) Ethernet LAN Black R1600

Roll over image to zoom inClick to Open expanded view

Synology RackStation RS422+ NAS/storage server Rack (1U) Ethernet LAN Black R1600

Name: Synology RackStation RS422+ NAS/storage server Rack (1U) Ethernet LAN Black R1600
Brand: Synology
SKU: RS422+

SKU: RS422+

Log In to View Pricing

Synology RackStation RS422+, NAS, Rack (1U), AMD Ryzen, R1600, Black

hypertec

Product manual (Download)

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Synology

Warranty
3 Years

Drive
Without Drives

SKU
RS422+

EAN
4711174724475

Bullet points

Point
601/516 MB/s sequential read/write throughput1

Built-in dual 1GbE ports with easy 10GbE option

CONNECTIVITY

Depth of just 327.5 mm with handles

ECC memory prevents data corruption

File Integrity

Form Factor

PERFORMANCE

Design

Chassis type
Rack (1U)

Cooling type
Active

Fan diameter
4 cm

LED indicators
Yes

Number of fans
3 fan(s)

Product colour
Black

Logistics data

Harmonized System (HS) code
84714100

Memory

ECC
Yes

Internal memory type
DDR4

Memory Installed
2 GB

Network

Ethernet LAN
Yes

Ethernet LAN data rates
1000 Mbit/s

Supported network protocols
SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPN, L2TP)

Wake-on-LAN ready
Yes

Operational conditions

Operating altitude
0 - 5000 m

Operating relative humidity (H-H)
8 - 80%

Operating temperature (T-T)
0 - 35 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
-20 - 60 °C

Other features

I/O ports
Console Port

Packaging content

Cables included
AC

Quick installation guide
Yes

Rack mount kit
Yes

Performance

Access Control List (ACL)
Yes

Backup function
Yes

Device class
Home & Home Office

Number of users
2048 user(s)

On/off switch
Yes

Reset button
Yes

Share folder
1024

Share folder access right management
Yes

Type
NAS

Ports & interfaces

Ethernet LAN (RJ-45) ports
2

Expansion ports quantity
1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1

USB port
Yes

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Processor

Number of Cores
2

On-board graphics card model
Not available

Processor
R1600

Processor boost frequency
3.1 GHz

Processor family
AMD Ryzen

Processor frequency
2.6 GHz

Processor manufacturer
AMD

Processor threads
4

Software

Operating system installed
DSM

Operating system version
7.1

Storage

Hot-swap drive bays
Yes

Installed storage drive type
No

Number of storage drives supported
4

RAID levels
0, 1, 5, 6, 10, JBOD

RAID support
Yes

Storage drive sizes supported
2.5,3.5"

Storage drives installed
No

Supported file systems
BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4

Supported storage drive interfaces
Serial ATA

Supported storage drive types
HDD & SSD

Technical details

Sustainability certificates
RoHS

Weight & dimensions

Depth
295.5 mm

Height
44 mm

Weight
4.38 kg

Width
430.5 mm

Description

Synology RackStation RS422+. Supported storage drive types: HDD & SSD, Supported storage drive interfaces: Serial ATA, Storage drive sizes supported: 2.5,3.5". Processor family: AMD Ryzen, Processor manufacturer: AMD, Processor model: R1600. Internal memory: 2 GB, Internal memory type: DDR4. Ethernet LAN data rates: 1000 Mbit/s, Supported network protocols: SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPN, L2TP). Chassis type: Rack (1U), Cooling type: Active, Product colour: Black

Home & Home Office NAS Rack (1U) Black
DSM 7.1
Number of storage drives supported: 4 HDD & SSD Serial ATA
AMD Ryzen R1600 2.6 GHz
2 DDR4 ECC
Ethernet LAN Wake-on-LAN ready
Cooling type: Active
Performance
601/516 MB/s sequential read/write throughput1
Form Factor
Depth of just 327.5 mm with handles
Connectivity
Built-in dual 1GbE ports with easy 10GbE option
File Integrity
ECC memory prevents data corruption
