QNAP QSW-M5216-1T network switch Managed L2 Black
Roll over image to zoom inClick to Open expanded view
QNAP QSW-M5216-1T network switch Managed L2 Black
QNAP QSW-M5216-1T network switch Managed L2 Black
QNAP QSW-M5216-1T network switch Managed L2 Black
QNAP QSW-M5216-1T network switch Managed L2 Black
QNAP QSW-M5216-1T network switch Managed L2 Black
QNAP QSW-M5216-1T network switch Managed L2 Black

QNAP QSW-M5216-1T network switch Managed L2 Black

SKU: QSW-M5216-1T
QNAP QSW-M5216-1T, Managed, L2, Rack mounting
Specifications
More Information
PDF

Product Properties

  • Warranty
  • 1 Year
  • SKU
  • QSW-M5216-1T
  • EAN
  • 4713213519134
  • Bullet points
  • Data transmission
  • Jumbo frames support
  • Yes
  • Design
  • Logistics data
  • Management features
  • Quality of Service (QoS) support
  • Yes
  • Web-based management
  • Yes
  • Network
  • Operational conditions
  • Packaging data
  • Cables included
  • AC
  • Performance
  • Firmware upgradeable
  • Yes
  • Ports & interfaces
  • Fiber ports quantity
  • 16
  • SFP28 ports quantity
  • 16
  • Power
  • Power consumption (max)
  • 80 W
  • Power supply included
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • No
  • Security
  • Access Control List (ACL)
  • Yes
  • Weight & dimensions

Description

QNAP QSW-M5216-1T. Switch type: Managed, Switch layer: L2. Console port: RS-232. MAC address table: 32000 entries, Switching capacity: 820 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE.... Rack mounting
  • Managed L2 Web-based management
  • Quality of Service (QoS) support
  • Console port: RS-232
  • 10G support
  • MAC address table: 32000 entries Switching capacity: 820 Gbit/s
  • Access Control List (ACL)
  • Rack mounting
  • AC Power supply included
  • The QSW-M5216-1T has sixteen 25GbE SFP28 fiber ports and a backbone switching capacity of 820Gbps for uplinking server rooms
  • The QSW-M5216-1T is equipped with one 10GbE NBASE-T port for hybrid high-speed network deployment
  • Featuring a user-friendly web UI, the QNAP Switch System (QSS) provides an overview dashboard, port management and setting guide, making central network management intuitive and easy
  • The QSW-M5216-1T provides Layer 2 management features (such as LACP, VLAN, ACL and LLDP) for efficiently controlling network bandwidth and enhance security
  • The QSW-M5216-1T supports Rapid Spanning Tree Protocol (RSTP). You can easily and efficiently deploy small/medium-scale networks that support expansion, redundancy, and loop prevention
  • Compliant with IEEE 802.3az Energy Efficient Ethernet and IEEE802.3x Flow Control in full-duplex mode, the QSW-M5216-1T avoids packet loss from unparalleled bandwidth and reduces power consumption for low-speed and inactive connections
