QNAP TS-H973AX NAS Tower Ryzen Embedded V1500B 32 GB DDR4 0 TB QuTS hero Black

Roll over image to zoom inClick to Open expanded view

QNAP TS-H973AX NAS Tower Ryzen Embedded V1500B 32 GB DDR4 0 TB QuTS hero Black

Name: QNAP TS-H973AX NAS Tower Ryzen Embedded V1500B 32 GB DDR4 0 TB QuTS hero Black
Brand: QNAP
SKU: TS-H973AX-32G

SKU: TS-H973AX-32G

QNAP TS-H973AX, NAS, Tower, Ryzen Embedded, V1500B, 32 GB, DDR4

hypertec

Product manual (Download)

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
QNAP

Warranty
1 Year

Drive
Without Drives

SKU
TS-H973AX-32G

EAN
4713213518663

Bullet points

Design

Cable lock slot
Yes

Cable lock slot type
Kensington

Chassis type
Tower

Cooling type
Active

Drive bay locking
Yes

Fan diameter
14 cm

LED indicators
HDD, LAN, Power, SSD, Status, USB

Number of fans
1 fan(s)

Product colour
Black

Logistics data

Harmonized System (HS) code
84714100

Memory

Flash memory
5000 MB

Internal memory type
DDR4

Maximum RAM supported
32 GB

Memory form factor
SO-DIMM

Memory Installed
32 GB

Memory slots
2

Network

Copper ethernet cabling technology
10GBASE-T

DHCP client
Yes

DHCP server
Yes

Dynamic DNS (DDNS)
Yes

Ethernet LAN
Yes

Ethernet LAN data rate supported (max)
10000 Mbit/s

Ethernet LAN data rates
100,1000,2500,5000,10000 Mbit/s

iSCSI support
Yes

Jumbo frames support
Yes

Link aggregation
Yes

Load balancing system
Yes

Supported network protocols
IPv4, IPv6

Wake-on-LAN ready
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
-20 - 70 °C

Packaging content

Cables included
AC, LAN (RJ-45)

Drive tray key included
Yes

External power adapter
Yes

Number of screws
56

Power cables quantity
1

Quick installation guide
Yes

Performance

Access Control List (ACL)
Yes

Backup features
Cloud, iSCSI LUN

Backup function
Yes

Browser supported
Apple Safari, Google Chrome, Microsoft Internet Explorer, Mozilla Firefox

Built-in FTP server
Yes

Buzzer
Yes

Device class
Small & Medium Business

Disk scan
Yes

Hot spare
Yes

Multilingual support
Yes

Noise level
22.9 dB

On/off switch
Yes

Password authentication
Yes

Reset button
Yes

S.M.A.R.T. support
Yes

Security algorithms
256-bit AES, HTTPS, SSH

Share folder
AFP, CIFS/SMB, FTP, WebDAV

Snapshot
Yes

System log
Yes

Third-party support
Yes

Type
NAS

USB copy function
Yes

Ports & interfaces

Concurrent connections
2000

Ethernet LAN (RJ-45) ports
3

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1

USB port
Yes

Power

AC input voltage
100 - 240 V

Fan voltage
12 V

Number of power supply units
1

Power consumption (HDD standby)
41.2 W

Power consumption (typical)
55.41 W

Power supply location
External

Power supply unit (PSU) capacity
120 W

Processor

Number of Cores
4

Processor
V1500B

Processor family
Ryzen Embedded

Processor frequency
2.2 GHz

Processor generation
AMD Ryzen Embedded V1000 Series

Processor manufacturer
AMD

Processor threads
8

Software

Linux operating systems supported
CentOS 7.0, SuSE Linux 12.0, SuSE Linux 12.3, SuSE Linux 15, Ubuntu 14.04, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10, Ubuntu 18.04 LTS, Ubuntu 20.04 LTS

Operating system installed
QuTS hero

Operating system version
h5.0.0

Other operating systems supported
IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11

Server operating systems supported
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Storage

Disk roaming
Yes

Hot-swap drive bays
Yes

Installed storage drive type
No

Number of storage drives installed
0

Number of storage drives supported
9

Online RAID expansion
Yes

RAID levels
0, 1, 5, 6, 10, 50, 60, JBOD

RAID rebuild
Yes

RAID support
Yes

Storage drive capacity
0 GB

Storage drive sizes supported
2.5,3.5"

Storage drives installed
No

Supported file systems
FAT32, HFS+, NTFS, ZFS, exFAT, ext3, ext4

Supported storage drive interfaces
Serial ATA II, Serial ATA III, U.2

Supported storage drive types
HDD & SSD

Total installed storage capacity
0 TB

Weight & dimensions

Depth
224.1 mm

Height
182.7 mm

Package weight
5.12 kg

Weight
3.52 kg

Width
224.6 mm

Description

QNAP TS-H973AX. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Processor family: Ryzen Embedded, Processor model: V1500B, Processor frequency: 2.2 GHz. Internal memory: 32 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB. Operating system installed: QuTS hero

Small & Medium Business NAS Tower Black
QuTS hero h5.0.0
Number of storage drives supported: 9 HDD & SSD Serial ATA II, Serial ATA III, U.2
Ryzen Embedded V1500B 2.2 GHz
32 DDR4 Memory slots: 2 SO-DIMM
Ethernet LAN 10000 DHCP server Jumbo frames support iSCSI support Wake-on-LAN ready
Cooling type: Active
Backup features: Cloud, iSCSI LUN 120 W
Install high-performance U.2 NVMe PCIe Gen 3 x4 SSDs or SATA 6Gb/s SSDs in the dedicated SSD slots for cache acceleration and improved random I/O
One 10GBASE-T Multi-Gig and two 2.5GbE LAN ports accelerate virtualization, intensive file access, large backup/restoration tasks, and media transfer
Experience a business-class backup center, supporting backup/restore of cloud data and VMs (including Google™ Workspace, Microsoft 365®, VMware® and Hyper-V)
Host multiple virtual machines and containers to run a wide range of applications on the TS-h973AX
Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud
Flexibly scale your total storage capacity to match your business growth by connecting USB expansion enclosures (TR series JBOD)
