• Design

• Chassis type
• Tower (5U)

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x16 (Gen 3.x) slots
• 4

• PCI Express x8 (Gen 2.x) slots
• 2

• Filters

• Machinecategory
• Server

• Graphics

• Maximum graphics card memory
• 16 MB

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2133 MHz

• Memory Installed
• 8 GB

• Memory Slot Support
• 1.54 TB

• Memory slots
• 24

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• Other features

• Graphics card
• G200

• Intel® Virtualization Technology (Intel® VT)
• VT-d, VT-x

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 2

• Power

• Power supply
• 750 W

• Processor

• Bus type
• QPI

• Compatible processor series
• Intel® Xeon®

• Conflict-Free processor
• No

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Idle States
• Yes

• Maximum internal memory supported by processor
• 768 GB

• Maximum number of PCI Express lanes
• 40

• Memory bandwidth supported by processor (max)
• 51 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 1600 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 6

• Number of processors installed
• 1

• Number of QPI links
• 2

• PCI Express configurations
• x4, x8, x16

• Physical Address Extension (PAE)
• 46 bit

• Processor
• E5-2603V3

• Processor cache
• 15 MB

• Processor cache type
• Smart Cache

• Processor codename
• Haswell

• Processor family
• Intel Xeon E5 v3

• Processor frequency
• 1.6 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 52.5 x 45 mm

• Processor series
• Intel Xeon E5-2600 v3

• Processor socket
• LGA 2011-v3

• Processor threads
• 6

• Scalability
• 2S

• Stepping
• R2

• Supported instruction sets
• AVX 2.0

• System bus rate
• 6.4 GT/s

• Tcase
• 72.8 °C

• Thermal Design Power (TDP)
• 85 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• Yes

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• No

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 83349

• Software

• Compatible operating systems
• Microsoft Windows Server 2008/2012 R2 Microsoft Windows Server 2008/2012 R2 SP2 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux

• Storage

• Hot-Plug support
• Yes

• Internal drive bays
• 8

• Optical drive type
• DVD±RW

• RAID support
• Yes

• Supported HDD sizes
• 3.5"

• Supported storage drive interfaces
• Serial ATA

• Weight & dimensions

• Depth
• 750.9 mm

• Height
• 443.5 mm

• Width
• 482 mm
