LevelOne Gigabit PoE Repeater, Cascadable

Roll over image to zoom inClick to Open expanded view

LevelOne Gigabit PoE Repeater, Cascadable

Name: LevelOne Gigabit PoE Repeater, Cascadable
Brand: LevelOne
SKU: POR-0120

SKU: POR-0120

LevelOne Gigabit PoE Repeater, Cascadable, Network repeater, 100 m, 1000 Mbit/s, Full, Half, 10/100/1000Base-T(X), IEEE 802.3af, IEEE 802.3x

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
LevelOne

Warranty
1 Year

SKU
POR-0120

EAN
4015867174920

Design

Certification
FCC Rules Part 15, CE

Country of origin
Taiwan

LED indicators
PoE, Power

Product colour
Black

Logistics data

Harmonized System (HS) code
85176990

Network

Cabling technology
10/100/1000Base-T(X)

Networking standards
IEEE 802.3af, IEEE 802.3x

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 50 °C

Storage temperature (T-T)
-20 - 90 °C

Packaging data

Package depth
235 mm

Package height
80 mm

Package weight
530 g

Package width
148 mm

Performance

Auto MDIX IEEE
Yes

Data transfer rate
1000 Mbit/s

Duplex system
Full, Half

Maximum transfer distance
100 m

Type
Network repeater

Ports & interfaces

Ethernet LAN (RJ-45) ports
2

Power over Ethernet (PoE) ports quantity
2

Power

Power consumption (max)
2.5 W

Power over Ethernet (PoE)
Yes

Weight & dimensions

Depth
120 mm

Height
28 mm

Weight
400 g

Width
90 mm

Description

LevelOne Gigabit PoE Repeater, Cascadable. Type: Network repeater, Maximum transfer distance: 100 m, Data transfer rate: 1000 Mbit/s. Cabling technology: 10/100/1000Base-T(X), Networking standards: IEEE 802.3af, IEEE 802.3x. Product colour: Black, LED indicators: PoE, Power, Country of origin: Taiwan. Power consumption (max): 2.5 W. Width: 90 mm, Depth: 120 mm, Height: 28 mm

Network repeater 100 m 1000 Mbit/s
10/100/1000Base-T(X)
Power over Ethernet (PoE)
Black
