NETGEAR MS305-100EUS network switch Unmanaged 2.5G Ethernet (100/1000/2500) Black

Roll over image to zoom inClick to Open expanded view

NETGEAR MS305-100EUS network switch Unmanaged 2.5G Ethernet (100/1000/2500) Black

Name: NETGEAR MS305-100EUS network switch Unmanaged 2.5G Ethernet (100/1000/2500) Black
Brand: Netgear
SKU: MS305-100EUS

SKU: MS305-100EUS

Log In to View Pricing

NETGEAR MS305-100EUS, Unmanaged, 2.5G Ethernet (100/1000/2500), Full duplex, Wall mountable

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Netgear

Warranty
3 Years

SKU
MS305-100EUS

EAN
606449160123

Data transmission

Forwarding rate
3.72 Mpps

Jumbo frames
9720

Jumbo frames support
Yes

Latency (1 Gbps)
2458 µs

Packet buffer memory
1 MB

Design

Housing material
Metal

LED indicators
Yes

Product colour
Black

Rack mounting
No

Stackable
No

Wall mountable
Yes

Management features

Quality of Service (QoS) support
Yes

Switch type
Unmanaged

Network

Auto MDI/MDI-X
Yes

Cable length detection
Yes

Ethernet LAN data rates
100,1000,2500 Mbit/s

Full duplex
Yes

Half duplex
Yes

Head-of-line (HOL) blocking
Yes

Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x

Operational conditions

Operating altitude
0 - 3000 m

Operating relative humidity (H-H)
0 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
0 - 95%

Storage temperature (T-T)
-20 - 70 °C

Performance

Fanless
Yes

Mean time between failures (MTBF)
1401743 h

Ports & interfaces

Switch Number of Ports
5

Switch Port Speed
2.5G Ethernet (100/1000/2500)

Power

DC input voltage
12 V

Input current
1 A

Input voltage
12 V

Power consumption (max)
9.24 W

Power consumption (typical)
4.6 W

Power source
DC

Power supply included
Yes

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Technical details

Compliance certificates
CCC, Low Voltage Directive (LVD)

Weight & dimensions

Depth
101 mm

Height
29 mm

Weight
480 g

Width
158 mm

Description

NETGEAR MS305-100EUS. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex, Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x. DC input voltage: 12 V. Wall mountable

Unmanaged
Quality of Service (QoS) support
Basic switching RJ-45 Ethernet ports quantity: 5
DC Power supply included
