SKU: XSM4328CV-100NES
NETGEAR M4350-24X4V, Managed, L3, 10G Ethernet (100/1000/10000), Power over Ethernet (PoE), Rack mounting, 1U
Specifications
More Information
PDF

Product Properties

  • Warranty
  • Lifetime
  • SKU
  • XSM4328CV-100NES
  • EAN
  • 606449161427
  • Bullet points
  • Data transmission
  • Jumbo frames support
  • Yes
  • Design
  • Management features
  • Quality of Service (QoS) support
  • Yes
  • Web-based management
  • Yes
  • Multicast features
  • Multicast Listener Discovery (MLD) snooping
  • Y
  • Network
  • Broadcast storm control
  • Yes
  • Flow control support
  • Yes
  • Policy-based routing
  • Yes
  • Spanning tree protocol
  • Yes
  • Operational conditions
  • Other features
  • Packaging data
  • Performance
  • Ports & interfaces
  • 10G Ethernet (copper) ports quantity
  • 24
  • SFP28 ports quantity
  • 4
  • Switch Number of Ports
  • 24
  • Power
  • Power supply included
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Power over Ethernet (PoE) power per port
  • 30 W
  • Power over Ethernet plus (PoE+) ports quantity
  • 24
  • Total Power over Ethernet (PoE) budget
  • 720 W
  • Protocols
  • GARP VLAN Registration Protocol (GVRP)
  • Yes
  • Security
  • Access Control List (ACL)
  • Yes
  • Access Control List (ACL) egress
  • 1023
  • Access Control List (ACL) ingress
  • 511
  • BPDU filtering/protection
  • Yes
  • DoS attack prevention
  • Yes
  • MAC address filtering
  • Yes
  • Password protection
  • Yes
  • Static port security
  • Yes
  • Sustainability
  • Sustainability compliance
  • Yes
  • Technical details
  • Weight & dimensions

Description

NETGEAR M4350-24X4V. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 16000 entries, Switching capacity: 680 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
  • Managed L3 Web-based management SNMP V1, V2, V3
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • 10G support
  • MAC address table: 16000 entries Switching capacity: 680 Gbit/s
  • Access Control List (ACL)
  • 1U Rack mounting Stackable
  • AC Power supply included Power over Ethernet (PoE)
  • 24 10G/Multi-Gig PoE+ ports with 4 25GBASE-X SFP28 uplinks
  • 880W internal power supply providing 576W of PoE budget
  • 1 slot for modular power supply (1+1 redundancy and/or EPS share)
  • Any APS350Wv1, APS600Wv2, APS920Wv1, or APS2000Wv1 can be used
  • The PoE budget can reach 720W, when the redundant PoE budget remains 576W
  • Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
  • Layer 3 feature set includes static, policy-based, and dynamic routing
  • NETGEAR IGMP Plus™, AV User Interface, and Engage Controller speed up AV installations
