NETGEAR GS324P Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

Roll over image to zoom inClick to Open expanded view

NETGEAR GS324P Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

Name: NETGEAR GS324P Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
Brand: Netgear
SKU: GS324P-100EUS

SKU: GS324P-100EUS

Log In to View Pricing

NETGEAR GS324P, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting, 1U

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Netgear

Warranty
3 Years

SKU
GS324P-100EUS

EAN
606449144802

Bullet points

Point
Built to last

ENERGY EFFICIENT

ETHERNET PORT CONFIGURATION: 24 Gigabit ports

PLUG-AND-PLAY: Simple set up with no software to install or configuration needed

POWER-OVER-ETHERNET

QUIET OPERATION: Ideal for noise-sensitive environments

VERSATILE MOUNTING OPTIONS

Data transmission

Jumbo frames
10000

Jumbo frames support
Yes

Latency (1 Gbps)
4 µs

MAC address table
8000 entries

Packet buffer memory
0.192 MB

Packet forwarding rate (1 Gbps)
1448000 pps

Switching capacity
48 Gbit/s

Design

Certification
CB, CE LVD, UL

Electromagnetic compatibility
CE, FCC 15 A, IC A, RCM, VCCI, KC

Form factor
1U

Housing material
Metal

LED indicators
Activity, Link, PoE, Power, Speed

Number of fans
1 fan(s)

Product colour
Black

Rack mounting
Yes

Logistics data

Harmonized System (HS) code
85176990

Management features

Quality of Service (QoS) support
Yes

Switch type
Unmanaged

Network

10G support
No

Auto MDI/MDI-X
Yes

Auto-negotiation
Yes

Full duplex
Yes

Networking standards
IEEE 802.1p, IEEE 802.3at

Operational conditions

Heat dissipation
718.2 BTU/h

Operating altitude
0 - 3000 m

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 45 °C

Storage relative humidity (H-H)
10 - 95%

Storage temperature (T-T)
-20 - 70 °C

Performance

Mean time between failures (MTBF)
1193574 h

Ports & interfaces

Switch Number of Ports
24

Switch Port Speed
Gigabit Ethernet (10/100/1000)

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Input current
3 A

Power consumption (max)
210 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes

Power over Ethernet (PoE) power per port
30 W

Power over Ethernet plus (PoE+) ports quantity
16

Total Power over Ethernet (PoE) budget
190 W

Security

Queue scheduling algorithms
Weighted Round Robin (WRR)

Weight & dimensions

Depth
206 mm

Height
43 mm

Weight
2.44 kg

Width
330 mm

Description

NETGEAR GS324P. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3at. Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Unmanaged
Quality of Service (QoS) support
Basic switching RJ-45 Ethernet ports quantity: 24
MAC address table: 8000 entries Switching capacity: 48 Gbit/s
1U Rack mounting
Power over Ethernet (PoE)
ETHERNET PORT CONFIGURATION: 24 Gigabit ports
POWER-OVER-ETHERNET: 16 PoE+ ports with 190W total power budget to power wireless AP, IP Cameras, IP Phones and much more
PLUG-AND-PLAY: Simple set up with no software to install or configuration needed
VERSATILE MOUNTING OPTIONS: Supports desktop, or rackmount placement, and includes all the necessary mounting hardware in the box
PoE POWER AUTO-BALANCE AND ALLOCATION - NETGEAR’s unique PoE technology automatically balances the PoE power at the most granular level on each port, depending on the device needs
QUIET OPERATION: Ideal for noise-sensitive environments
ENERGY EFFICIENT: Designed to optimize power usage lowering its cost to operate. Compliant with IEEE802.3az Energy Efficient Ethernet mode
BUILT TO LAST: Every NETGEAR Network switch is rigorously tested for reliability, quality, and performance
