LevelOne TURING 26-Port Web Smart Gigabit PoE Switch, 24 PoE Outputs, 2 x SFP/RJ45 Combo, 185W, 802.3at/af PoE

Roll over image to zoom inClick to Open expanded view

LevelOne TURING 26-Port Web Smart Gigabit PoE Switch, 24 PoE Outputs, 2 x SFP/RJ45 Combo, 185W, 802.3at/af PoE

Name: LevelOne TURING 26-Port Web Smart Gigabit PoE Switch, 24 PoE Outputs, 2 x SFP/RJ45 Combo, 185W, 802.3at/af PoE
Brand: LevelOne
SKU: GEP-2651

SKU: GEP-2651

LevelOne TURING 26-Port Web Smart Gigabit PoE Switch, 24 PoE Outputs, 2 x SFP/RJ45 Combo, 185W, 802.3at/af PoE, Managed, L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting

hypertec

Product manual (Download)

EU Declaration of Conformity (Download)

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
LevelOne

Warranty
1 Year

SKU
GEP-2651

EAN
4015867198957

Data transmission

Forwarding rate
38.7 Mpps

Jumbo frames
9600

Jumbo frames support
Yes

MAC address table
8000 entries

Static route
Yes

Store-and-forward
Yes

Switching capacity
52 Gbit/s

Design

Certification
CE, FCC Part 15 Class A, RoHS

Country of origin
Taiwan

LED indicators
Activity, Link, PoE, Speed

Product colour
Black

Rack mounting
Yes

Reset button
Yes

Logistics data

Harmonized System (HS) code
85176990

Master (outer) case gross weight
21 kg

Master (outer) case height
324 mm

Master (outer) case length
540 mm

Master (outer) case width
482 mm

Products per master (outer) case
5 pc(s)

Management features

Quality of Service (QoS) support
Yes

Switch layer
L3

Switch type
Managed

System event log
Yes

Web-based management
Yes

Network

Broadcast storm control
Yes

Cable length detection
Yes

Copper ethernet cabling technology
100BASE-TX, 1000BASE-T

Flow control support
Yes

Link aggregation
Yes

MAC address auto-aging supported
Yes

MAC address auto-learning supported
Yes

Number of VLANs
256

Port mirroring
Yes

Spanning tree protocol
Yes

Virtual LAN features
Tagged VLAN, MAC address-based VLAN, Port-based VLAN

VLAN support
Yes

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 45 °C

Storage relative humidity (H-H)
10 - 90%

Storage temperature (T-T)
-20 - 70 °C

Optical fiber

Fiber ethernet cabling technology
1000BASE-X

Packaging data

Cables included
AC

Manual
Yes

Package depth
520 mm

Package height
90 mm

Package weight
3.5 kg

Package width
300 mm

Quick start guide
Yes

Performance

Buffer size
512 KB

Firmware upgradeable
Yes

Flash memory
32 MB

Internal memory
128 MB

Mean time between failures (MTBF)
211272 h

Ports & interfaces

Combo SFP ports quantity
2

Gigabit Ethernet (copper) ports quantity
24

Switch Number of Ports
24

Switch Port Speed
Gigabit Ethernet (10/100/1000)

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Power consumption (typical)
18.29 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes

Power over Ethernet (PoE) power per port
30 W

Power over Ethernet plus (PoE+) ports quantity
24

Total Power over Ethernet (PoE) budget
185 W

Protocols

Supported network protocols
IPv4/IPv6

Security

Access Control List (ACL)
Yes

BPDU filtering/protection
Yes

DHCP features
DHCP server, DHCP snooping, DHCP client

IGMP snooping
Yes

Loop protection
Yes

Security algorithms
802.1x RADIUS

Static port security
Yes

Weight & dimensions

Depth
211 mm

Height
44 mm

Weight
3.1 kg

Width
442 mm

Description

LevelOne TURING 26-Port Web Smart Gigabit PoE Switch, 24 PoE Outputs, 2 x SFP/RJ45 Combo, 185W, 802.3at/af PoE. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 52 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE.... Power over Ethernet (PoE). Rack mounting

Managed L3 Web-based management
Quality of Service (QoS) support
Basic switching RJ-45 Ethernet ports quantity: 24
100BASE-TX, 1000BASE-T
MAC address table: 8000 entries Switching capacity: 52 Gbit/s
Access Control List (ACL)
Rack mounting
Power over Ethernet (PoE)
