LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km
Roll over image to zoom inClick to Open expanded view
LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km
LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km
LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km
LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km
LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km
LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km

LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km

SKU: GVT-2014
LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km, 1000 Mbit/s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, 10,100,1000 Mbit/s, 10BASE-T, 100BASE-T, 1000BASE-T, Full, Half, SC
Specifications
More Information
PDF

Product Properties

  • Warranty
  • 1 Year
  • SKU
  • GVT-2014
  • EAN
  • 4015867231227
  • Bullet points
  • Design
  • Logistics data
  • Network
  • Flow control support
  • Yes
  • Jumbo frames support
  • Yes
  • Operational conditions
  • Packaging content
  • AC adapter included
  • Yes
  • Packaging data
  • Performance
  • Ports & interfaces
  • Ethernet LAN (RJ-45) ports
  • 1
  • Fiber optic connector
  • SC
  • Fiber ports quantity
  • 1
  • Power
  • External power adapter
  • Yes
  • Power consumption (max)
  • 40 W
  • Power over Ethernet (PoE)
  • Yes
  • Total Power over Ethernet (PoE) budget
  • 30 W
  • Weight & dimensions

Description

LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km. Maximum data transfer rate: 1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, Ethernet LAN data rates: 10,100,1000 Mbit/s. Fiber optic connector: SC, Connectivity technology: Wired. Maximum transfer distance: 20000 m, Wavelength: 1310 nm, Fiber mode structure: Single-mode. LED indicators: Activity, Link, Power, Product colour: Grey, Country of origin: China. Input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz, Input current: 1.6 A
  • Wired
  • 1000 Mbit/s 20000 m 1310 nm
  • 10BASE-T, 100BASE-T, 1000BASE-T
  • Ethernet LAN (RJ-45) ports: 1
  • Single-mode Fiber ports quantity: 1 SC
  • Grey
  • "Transfers data from 10/100/1000Base-T copper to fiber interfaces
  • Single-Mode fiber with SC connector for transmission of up to 20km
  • IEEE 802.3af/at PoE PSE with 30W power budget
  • 9K jumbo frames to increase data transfer rates
  • 1000Mbps full-duplex, 10/100Mbps full/half-duplex, auto-negotiation, auto-MDI/MDIX
  • IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
  • IEEE 802.3z Gigabit Ethernet compliant"
