LevelOne PoE over Hybrid Cable Transmitter, 120W

Roll over image to zoom inClick to Open expanded view

LevelOne PoE over Hybrid Cable Transmitter, 120W

Name: LevelOne PoE over Hybrid Cable Transmitter, 120W
Brand: LevelOne
SKU: PFE-1101T

SKU: PFE-1101T

LevelOne PoE over Hybrid Cable Transmitter, 120W, Network transmitter, 2000 m, 100 Mbit/s, Full, 10/100Base-T(X), IEEE 802.3, IEEE 802.3u, IEEE 802.3x

hypertec

Generated PDF (Download)

Add to compare

Product Properties

Manufacturer
LevelOne

Warranty
1 Year

SKU
PFE-1101T

EAN
5050914834197

Design

Certification
CE, FCC

LED indicators
LAN, PoE, Power

Product colour
Black

Logistics data

Harmonized System (HS) code
85176990

Network

Cabling technology
10/100Base-T(X)

Networking standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 50 °C

Storage relative humidity (H-H)
5 - 90%

Storage temperature (T-T)
0 - 60 °C

Packaging content

AC adapter included
Yes

Quick start guide
Yes

Packaging data

Package depth
146 mm

Package height
78 mm

Package weight
200 g

Package width
222 mm

Performance

Auto MDIX IEEE
Yes

Auto-negotiation
Yes

Data transfer rate
100 Mbit/s

Duplex system
Full

Maximum transfer distance
2000 m

Type
Network transmitter

Ports & interfaces

Ethernet LAN (RJ-45) ports
1

Power

AC input frequency
50 - 60 Hz

AC input voltage
100-240 V

External power adapter
Yes

Power consumption (typical)
120 W

Power over Ethernet (PoE)
Yes

Weight & dimensions

Depth
90 mm

Height
28 mm

Weight
250 g

Width
133 mm

Description

LevelOne PoE over Hybrid Cable Transmitter, 120W. Type: Network transmitter, Maximum transfer distance: 2000 m, Data transfer rate: 100 Mbit/s. Cabling technology: 10/100Base-T(X), Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x. Product colour: Black, LED indicators: LAN, PoE, Power, Certification: CE, FCC. AC input voltage: 100-240 V, AC input frequency: 50 - 60 Hz, Power consumption (typical): 120 W. Width: 133 mm, Depth: 90 mm, Height: 28 mm

Network transmitter 2000 m 100 Mbit/s
10/100Base-T(X)
Power over Ethernet (PoE)
Black
