LevelOne 48V DC Industrial Power Supply, 75W, DIN-Rail, PoE Ready

Roll over image to zoom inClick to Open expanded view

LevelOne 48V DC Industrial Power Supply, 75W, DIN-Rail, PoE Ready

Name: LevelOne 48V DC Industrial Power Supply, 75W, DIN-Rail, PoE Ready
Brand: LevelOne
SKU: POW-4821

SKU: POW-4821

LevelOne 48V DC Industrial Power Supply, 75W, DIN-Rail, PoE Ready, 75 W, 90 - 264 V, 76.8 W, Over voltage, Overload, Short circuit, 506600 h, UL508, TUV EN60950-1, EAC TP TC 004, BSMI CNS14336-1 approved;(meet EN60204-1)

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
LevelOne

Warranty
1 Year

SKU
POW-4821

EAN
4015867206485

Bullet points

Design

LED indicators
Yes

Product colour
Mint colour, Silver

Logistics data

Harmonized System (HS) code
84733020

Operational conditions

Operating relative humidity (H-H)
20 - 95%

Operating temperature (T-T)
-20 - 60 °C

Other features

Maximum current
1.6 A

Power over Ethernet (PoE)
Yes

Technical features
48V DC Out

Packaging data

Package depth
102 mm

Package height
32 mm

Package weight
510 g

Package width
125.2 mm

Performance

Country of origin
China

Mean time between failures (MTBF)
506600 h

Power

AC input voltage
90 - 264 V

Peak power
76.8 W

Power protection features
Over voltage, Overload, Short circuit

Total power
75 W

Weight & dimensions

Depth
102 mm

Height
32 mm

Weight
510 g

Width
125.2 mm

Description

LevelOne 48V DC Industrial Power Supply, 75W, DIN-Rail, PoE Ready. Total power: 75 W, AC input voltage: 90 - 264 V, Peak power: 76.8 W. Mean time between failures (MTBF): 506600 h, Safety: UL508, TUV EN60950-1, EAC TP TC 004, BSMI CNS14336-1 approved;(meet EN60204-1), Country of origin: China. Product colour: Mint colour, Silver. Width: 125.2 mm, Depth: 102 mm, Height: 32 mm. Package width: 125.2 mm, Package depth: 102 mm, Package height: 32 mm

Universal AC Input at Full Range
Short Circuit, Overload / Over Voltage Protection
Fanless Design
Supports DIN-rail installation
100% Full Load Burn-in Test
UL 508 approval
