• Audio

• Audio chip
• Realtek ALC3286

• Audio system
• Dolby Audio Premium

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Number of microphones
• 2

• Speaker power
• 2 W

• Battery

• Battery capacity
• 90 Wh

• Battery technology
• Lithium-Ion (Li-Ion)

• Number of battery cells
• 6

• Camera

• Auto focus
• No

• Front camera
• Yes

• Front camera HD type
• HD

• Front camera resolution
• 1280 x 720 pixels

• Front camera signal format
• 720p

• Infrared (IR) camera
• Yes

• Design

• Form factor
• Clamshell

• Housing material
• Aluminium, Magnesium

• Product colour
• Black

• Product type
• Mobile workstation

• Display

• Display surface
• Matt

• HD type
• Full HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Panel type
• IPS

• Screen Resolution
• 1920 x 1080 pixels

• Screen Size
• 39.6 cm (15.6")

• Touchscreen
• No

• Filters

• Machinecategory
• Mobile workstation

• Graphics

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 4 GB

• Discrete graphics card model
• NVIDIA® Quadro® P2000

• Maximum on-board graphics card memory
• 64 GB

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1200 MHz

• On-board graphics card family
• Intel® UHD Graphics

• On-board graphics card ID
• 0x3E9B

• On-board graphics card model
• Intel UHD Graphics P630

• On-board graphics card OpenGL version
• 4.5

• Keyboard

• Keyboard backlit
• Yes

• Numeric keypad
• Yes

• Pointing device
• ThinkPad UltraNav

• Spill-resistant keyboard
• Yes

• Windows keys
• Yes

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2400 MHz

• Memory form factor
• SO-DIMM

• Memory Installed
• 32 GB

• Memory Slot Support
• 64 GB

• Memory slots
• 4x SO-DIMM

• Network

• Antenna type
• 2x2

• Bluetooth
• Yes

• Bluetooth version
• 5.0

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Top Wi-Fi standard
• Wi-Fi 5 (802.11ac)

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

• Other features

• 3D
• No

• AC adapter included
• Yes

• Maximum internal memory (64-bit)
• 64 GB

• Packaging content

• Manual
• Yes

• Power cord included
• Yes

• Ports & interfaces

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• Docking connector
• Yes

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• HDMI version
• 2.0

• Headphone outputs
• 1

• Microphone in
• No

• Mini DisplayPorts quantity
• 1

• SmartCard slot
• Yes

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 3

• USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
• 2

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 1

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter power
• 170 W

• Processor

• Bus type
• DMI

• Configurable TDP-down
• 35 W

• Configurable TDP-down frequency
• 2.2 GHz

• ECC supported by processor
• Yes

• Maximum number of PCI Express lanes
• 16

• Motherboard chipset
• Intel® CM246

• Number of Cores
• 6

• PCI Express configurations
• 1x16, 1x8+2x4, 2x8

• PCI Express slots version
• 3.0

• Processor
• E-2176M

• Processor boost frequency
• 4.4 GHz

• Processor cache
• 12 MB

• Processor cache type
• Smart Cache

• Processor codename
• Coffee Lake

• Processor family
• Intel® Xeon®

• Processor frequency
• 2.7 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• BGA 1440

• Processor threads
• 12

• Stepping
• U0

• System bus rate
• 8 GT/s

• Thermal Design Power (TDP)
• 45 W

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• Yes

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Stable Image Platform Program (SIPP) version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 134867

• Processor code
• SR3YX

• Processor package size
• 42 x 28 mm

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Fingerprint reader
• Yes

• Password protection
• Yes

• Password protection type
• HDD, Power on, Supervisor

• Trusted Platform Module (TPM)
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro for Workstations

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• MMC, SD, SDHC, SDXC

• Number of SSDs installed
• 1

• Optical drive type
• No

• SSD capacity
• 1 TB

• SSD form factor
• M.2

• Storage Capacity
• 1 TB

• Storage type
• SSD

• Sustainability

• Sustainability certificates
• RoHS, EPEAT Gold, ENERGY STAR

• Weight & dimensions

• Depth
• 252.3 mm

• Height (front)
• 2.45 cm

• Height (rear)
• 2.94 cm

• Weight
• 2.45 kg

• Width
• 377.4 mm
