• Bullet points

• Point
• 1x 128GB SSD M.2 2242 PCIe 3.0x2 NVMe
  2x 8GB SO-DIMM DDR4-2666
  Intel Core i7-9700T (8C/8T, 2.0/4.3GHz, 12MB)
  Intel UHD Graphics 630
  Windows 10 IoT Enterprise

• Certificates

• Certification
• MIL-STD-810G

• Design

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Chassis type
• mini PC

• Colour name
• Black

• Intel® vPro™ Platform Eligibility
• Yes

• Placement supported
• Horizontal/Vertical

• Product colour
• Black

• VESA mounting
• Yes

• Volume
• 1 L

• Filters

• Machinecategory
• Personal computer

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• Maximum on-board graphics card memory
• 64 GB

• Number of displays supported (on-board graphics)
• 3

• On-board GPU manufacturer
• Intel

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1200 MHz

• On-board graphics card ID
• 0x3E98

• On-board graphics card model
• Intel® UHD Graphics 630

• On-board graphics card OpenGL version
• 4.5

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2666 MHz

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 2 x 8 GB

• Memory Slot Support
• 32 GB

• Memory slots
• 2x SO-DIMM

• Network

• Antenna type
• 2x2

• Bluetooth
• Yes

• Bluetooth version
• 5.0

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Top Wi-Fi standard
• Wi-Fi 5 (802.11ac)

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

• WLAN controller manufacturer
• Intel

• WLAN controller model
• Intel Dual Band Wireless-AC 9560

• Packaging content

• Display included
• No

• Keyboard included
• Yes

• Mouse included
• Yes

• VESA mount included
• Yes

• Performance

• Audio chip
• Realtek ALC233VB2

• Audio system
• High Definition Audio

• Motherboard chipset
• Intel Q370

• Number of speakers
• 1

• Password protection
• Yes

• Product type
• Mini PC

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• Combo headphone/mic port
• Yes

• DisplayPorts quantity
• 1

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• Headphone outputs
• 1

• Microphone in
• Yes

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 3

• USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
• 1

• USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
• 2

• Power

• Power supply
• 135 W

• Processor

• Configurable TDP-down
• 25 W

• Configurable TDP-down frequency
• 1.5 GHz

• Maximum internal memory supported by processor
• 128 GB

• Maximum number of PCI Express lanes
• 16

• Memory bandwidth supported by processor (max)
• 41.6 GB/s

• Memory clock speeds supported by processor
• 2666 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 8

• Number of processors installed
• 1

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• PCI Express slots version
• 3.0

• Processor
• i7-9700T

• Processor boost frequency
• 4.3 GHz

• Processor cache
• 12 MB

• Processor cache type
• Smart Cache

• Processor codename
• Coffee Lake

• Processor family
• Intel® Core™ i7

• Processor frequency
• 2 GHz

• Processor generation
• 9th gen Intel® Core™ i7

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• LGA 1151 (Socket H4)

• Processor threads
• 8

• System bus rate
• 8 GT/s

• Thermal Design Power (TDP)
• 35 W

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 191048

• Processor package size
• 37.5 x 37.5 mm

• Scalability
• 1S

• Supported instruction sets
• SSE4.1, SSE4.2, AVX 2.0

• Thermal Monitoring Technologies
• Yes

• Thermal solution specification
• PCG 2015A

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 IoT Enterprise

• Storage

• Card reader integrated
• No

• Number of SSDs installed
• 1

• Number of storage drives installed
• 1

• Optical drive type
• No

• SSD capacity
• 128 GB

• SSD form factor
• M.2

• SSD interface
• PCI Express

• Storage Capacity
• 128 GB

• Storage type
• SSD

• Total SSDs capacity
• 128 GB

• Sustainability

• Sustainability certificates
• RoHS, ENERGY STAR

• Weight & dimensions

• Depth
• 182.9 mm

• Height
• 34.5 mm

• Weight
• 1.32 kg

• Width
• 179 mm
