• Bullet points

• Point
• 4GB (2666MHz) DDR4-SDRAM (1 x 4) & 500GB HDD
  Intel Core i3-8145U (4MB Cache, 2.1GHz)
  Windows 10 Pro 64-bit

• Design

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Chassis type
• UFF

• Product colour
• Black

• Filters

• Machinecategory
• Personal computer

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• Maximum on-board graphics card memory
• 32 GB

• Number of displays supported (on-board graphics)
• 3

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 300 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1000 MHz

• On-board graphics card ID
• 0x3EA0

• On-board graphics card model
• Intel® UHD Graphics

• On-board graphics card OpenGL version
• 4.5

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory channels
• Dual-channel

• Memory clock speed
• 2666 MHz

• Memory Installed
• 4 GB

• Memory layout (slots x size)
• 1 x 4 GB

• Memory Slot Support
• 64 GB

• Memory slots
• 2x SO-DIMM

• Network

• Bluetooth
• Yes

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Top Wi-Fi standard
• Wi-Fi 6 (802.11ax)

• Wi-Fi
• Yes

• Wi-Fi standards
• Wi-Fi 6 (802.11ax)

• WLAN controller model
• Intel Wi-Fi 6 AX200

• Operational conditions

• Non-operating altitude
• -15.2 - 10668 m

• Non-operating shock
• 160 G

• Non-operating vibration
• 1.3 G

• Operating altitude
• -15.2 - 3048 m

• Operating relative humidity (H-H)
• 10 - 90%

• Operating shock
• 110 G

• Operating temperature (T-T)
• 0 - 35 °C

• Operating vibration
• 0.66 G

• Storage relative humidity (H-H)
• 0 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Packaging content

• AC adapter included
• Yes

• Display included
• No

• Keyboard included on selected markets only
• Yes

• Manual
• Yes

• Mouse included on selected markets only
• Yes

• Power cord included
• Yes

• Performance

• Audio chip
• Realtek ALC3204-CG

• Product type
• Mini PC

• Ports & interfaces

• Combo headphone/mic port
• Yes

• DC-in jack
• Yes

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• Microphone in
• No

• Number of USB ports with PowerShare support
• 1

• On/off button
• Yes

• PowerShare
• Yes

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 1

• USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
• 2

• USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
• 2

• Power

• Power supply
• 65 W

• Power supply input frequency
• 50 - 60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Bus type
• OPI

• Configurable TDP-down
• 10 W

• Configurable TDP-down frequency
• 0.8 GHz

• Configurable TDP-up
• 25 W

• Configurable TDP-up frequency
• 2.3 GHz

• Maximum internal memory supported by processor
• 32 GB

• Maximum number of PCI Express lanes
• 16

• Memory bandwidth supported by processor (max)
• 37.5 GB/s

• Memory clock speeds supported by processor
• 2133,2400 MHz

• Memory types supported by processor
• DDR4-SDRAM, LPDDR3-SDRAM

• Number of Cores
• 2

• Number of processors installed
• 1

• PCI Express configurations
• 1x2+2x1, 1x4, 2x2, 4x1

• PCI Express slots version
• 3.0

• Processor
• i3-8145U

• Processor boost frequency
• 3.9 GHz

• Processor cache
• 4 MB

• Processor cache type
• Smart Cache

• Processor codename
• Whiskey Lake

• Processor family
• Intel® Core™ i3

• Processor frequency
• 2.1 GHz

• Processor generation
• 8th gen Intel® Core™ i3

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• BGA 1528

• Processor threads
• 4

• System bus rate
• 4 GT/s

• Thermal Design Power (TDP)
• 15 W

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Smart Response Technology version
• 1.00

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Trusted Execution Technology
• No

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Smart Response Technology
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 149090

• Processor package size
• 46x24 mm

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Operating system language
• Multilingual

• Trial software
• Microsoft Office

• Storage

• Card reader integrated
• No

• HDD capacity
• 500 GB

• HDD interface
• SATA

• HDD size
• 2.5"

• HDD speed
• 7200 RPM

• Number of HDDs installed
• 1

• Optical drive type
• No

• Storage Capacity
• 500 GB

• Storage type
• HDD

• Total HDDs capacity
• 500 GB

• Weight & dimensions

• Depth
• 19.7 mm

• Height
• 256.2 mm

• Package depth
• 297 mm

• Package height
• 213 mm

• Package weight
• 5.33 kg

• Package width
• 494 mm

• Weight
• 650 g

• Width
• 96.1 mm
