• Design

• Chassis type
• SFF

• Country of origin
• China

• Product colour
• Black

• Expansion slots

• PCI Express x1 slots
• 3

• PCI Express x16 slots
• 1

• Graphics

• Discrete graphics card model
• Not available

• Maximum on-board graphics card memory
• 1.74 GB

• Number of displays supported (on-board graphics)
• 3

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 11.1

• On-board graphics card dynamic frequency (max)
• 1150 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0x41E

• On-board graphics card memory
• 1.7 GB

• On-board graphics card model
• Intel® HD Graphics 4400

• Memory

• Internal memory type
• DDR3-SDRAM

• Memory channels
• Dual-channel

• Memory clock speed
• 1600 MHz

• Memory Installed
• 4 GB

• Memory layout (slots x size)
• 1 x 4 GB

• Memory Slot Support
• 16 GB

• Memory slots
• 2x DIMM

• Network

• Bluetooth
• No

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wi-Fi
• No

• Wi-Fi standards
• Not supported

• Operational conditions

• Operating relative humidity (H-H)
• 10 - 90%

• Operating temperature (T-T)
• 10 - 35 °C

• Storage relative humidity (H-H)
• 5 - 90%

• Storage temperature (T-T)
• -20 - 60 °C

• Other features

• Intel segment tagging
• Enterprise, Small Business

• LightScribe
• No

• Optical drives quantity
• 1

• Packaging content

• AC adapter included
• No

• Display included
• No

• Keyboard included
• Yes

• Mouse included
• Yes

• Performance

• Motherboard chipset
• Intel® H81

• Product type
• PC

• Ports & interfaces

• Combo headphone/mic port
• No

• DC-in jack
• No

• DVI port
• Yes

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 1

• Line-in
• Yes

• Line-out
• Yes

• Microphone in
• Yes

• PS/2 ports quantity
• 2

• S/PDIF out port
• No

• Serial ports quantity
• 1

• SmartCard slot
• No

• USB 2.0 ports quantity
• 6

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• VGA (D-Sub) ports quantity
• 1

• Power

• Power supply
• 240 W

• Power supply input frequency
• 50 - 60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Bus type
• DMI2

• ECC supported by processor
• Yes

• FSB Parity
• No

• Maximum internal memory supported by processor
• 32 GB

• Maximum number of PCI Express lanes
• 16

• Memory bandwidth supported by processor (max)
• 25.6 GB/s

• Memory clock speeds supported by processor
• 1333,1600 MHz

• Memory types supported by processor
• DDR3-1333/1600, DDR3L-1333/1600 @ 1.5V

• Number of Cores
• 2

• Number of processors installed
• 1

• PCI Express configurations
• 1x8, 1x16, 2x4, 2x8

• PCI Express slots version
• 3.0

• Processor
• i3-4130

• Processor cache
• 3 MB

• Processor cache type
• Smart Cache

• Processor codename
• Haswell

• Processor family
• Intel® Core™ i3

• Processor frequency
• 3.4 GHz

• Processor generation
• 4th gen Intel® Core™ i3

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i3-4100 Desktop series

• Processor socket
• LGA 1150 (Socket H3)

• Processor threads
• 4

• Stepping
• C0

• System bus rate
• 5 GT/s

• Tcase
• 72 °C

• Thermal Design Power (TDP)
• 65, 54

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 22 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Rapid Storage Technology
• No

• Intel Small Business Advantage (SBA) version
• 1.00

• Intel Smart Connect Technology
• No

• Intel Stable Image Platform Program (SIPP)
• No

• Intel Stable Image Platform Program (SIPP) version
• 0.00

• Intel Trusted Execution Technology
• No

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• No

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® Active Management Technology (Intel® AMT)
• No

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® High Definition Audio (Intel® HD Audio)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• Yes

• Intel® Matrix Storage Technology (Intel® MST)
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• Yes

• Intel® Rapid Start Technology
• No

• Intel® Small Business Advantage (Intel® SBA)
• Yes

• Intel® Smart Response Technology
• No

• Intel® Turbo Boost Technology
• No

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 77480

• Processor package size
• 37.5 x 37.5 mm

• Scalability
• 1S

• Supported instruction sets
• AVX 2.0

• Thermal Monitoring Technologies
• Yes

• Thermal solution specification
• PCG 2013C

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Recovery operating system
• Windows 8.1 Pro

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• MMC, SD, SDXC, SDHC

• HDD capacity
• 500 GB

• HDD interface
• SATA

• HDD speed
• 7200 RPM

• Number of storage drives installed
• 1

• Optical drive type
• DVD Super Multi

• Storage Capacity
• 500 GB

• Storage type
• HDD

• Total HDDs capacity
• 500 GB

• Sustainability

• Sustainability certificates
• RoHS, EPEAT Silver, ENERGY STAR

• Weight & dimensions

• Depth
• 380.5 mm

• Height
• 100 mm

• Weight
• 5.9 kg

• Width
• 337 mm
