Equip Eco Mount 19' Cabinet, 07U, 540X400MM, RAL7035 Grey

Roll over image to zoom inClick to Open expanded view

Equip Eco Mount 19' Cabinet, 07U, 540X400MM, RAL7035 Grey

Name: Equip Eco Mount 19' Cabinet, 07U, 540X400MM, RAL7035 Grey
Brand: LevelOne
SKU: 280323

SKU: 280323

Log In to View Pricing

Equip Eco Mount 19' Cabinet, 07U, 540X400MM, RAL7035 Grey, Wall mounted rack, 7U, Key lock, 9.06 kg, Light grey

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
LevelOne

Warranty
2 Years

SKU
280323

EAN
4015867235942

Bullet points

Point
07U 10 inch cabinet, designed for optimal performance in every space

540X400MM Mountable Network Cabinet

Ships in a flatpack for easy transportation

The cabinet comes with a sleek glass frontdoor to elegantly showcase your equipment

Features

Adjustable depth
No

Adjustable feet
No

Adjustable stand
No

Assembly required
No

Back door construction
Steel

Back door key lock
No

Built-in UPS
No

Cable management
No

Castor wheels
No

Cooling type
Passive

Door opening angle
200°

Frame type
Closed

Front door construction
Tempered glass

Front door key lock
Yes

Key lock
Yes

Main PDU
No

Material
Steel

Monitoring
No

Mounting hole shape
Square

Preassembled
Yes

Product colour
Light grey

Product design
2-post

Rack capacity
7U

Rack rail thickness
1.5 mm

Rack rails
No

Removable back door
No

Removable front door
Yes

Removable side panels
No

Side panel construction
Steel

Side panel key lock
No

Side panels included
No

Soundproof
No

Stabilising foot screw
No

Type
Wall mounted rack

Logistics data

Country of origin
Turkey

Harmonized System (HS) code
853710980019

Other features

Layers per pallet
10 pc(s)

Master (outer) cases per pallet
50 pc(s)

Products per pallet
50 pc(s)

Packaging data

Grounding kit
No

Manual
No

Mounting kit
No

Number of nuts
10

Number of screws
10

Nuts included
Yes

Package depth
577 mm

Package height
174 mm

Package width
465 mm

Plinth panel
No

Quick installation guide
No

Screws included
Yes

Temperature sensor
No

Wall mounting kit
Yes

Technical details

Pallet net height
190 cm

Pallet net length
110 cm

Pallet net width
130 cm

Total carbon footprint
1.5493 kg of CO2e

Weight & dimensions

Depth
400 mm

Height
330 mm

Inner depth
39.5 cm

Inner height
31.2 cm

Inner width
49.5 cm

Mounting depth (max)
38 cm

Mounting depth (min)
36 cm

Size (imperial)
31 cm (12.2")

Weight
9.06 kg

Width
174 mm

Description

Equip Eco Mount 19' Cabinet, 07U, 540X400MM, RAL7035 Grey. Type: Wall mounted rack, Rack capacity: 7U, Key lock. Weight: 9.06 kg. Product colour: Light grey

7U Wall mounted rack
Frame type: Closed 2-post
Removable front door
Steel
Light grey
07U 10 inch cabinet, designed for optimal performance in every space
540X400MM Mountable Network Cabinet
Ships in a flatpack for easy transportation
The cabinet comes with a sleek glass frontdoor to elegantly showcase your equipment
