Conceptronic EMRICK M.2 NVMe SSD PCIe Adapter

Roll over image to zoom inClick to Open expanded view

Conceptronic EMRICK M.2 NVMe SSD PCIe Adapter

Name: Conceptronic EMRICK M.2 NVMe SSD PCIe Adapter
Brand: Conceptronic
SKU: EMRICK05BS

SKU: EMRICK05BS

Conceptronic EMRICK M.2 NVMe SSD PCIe Adapter, PCIe, M.2, PCIe 3.0, China, Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., 40 mm

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Conceptronic

Warranty
2 Years

SKU
EMRICK05BS

EAN
4015867223680

Bullet points

Point
Compatible with x4, x8, and x16 standard and low-profile PCI Express slots

NOT compatible with B Key M.2 PCI x2 SSD or B Key M.2 SATA SSD

Simple Plug and Play installation

Supports M Key and B+M Key M.2 SSD

Supports M.2 PCIe NVMe SSD including 2230, 2242, 2260, and 2280 drives

Supports PCIe Gen 3.0 x4

Design

Country of origin
China

Internal
Yes

Features

Plug and Play
Yes

Logistics data

Harmonized System (HS) code
84733020

Master (outer) case gross weight
3.7 kg

Master (outer) case height
415 mm

Master (outer) case length
180 mm

Master (outer) case width
280 mm

Products per master (outer) case
30 pc(s)

Packaging data

Mounting brackets included
Yes

Package depth
156 mm

Package height
26 mm

Package weight
110 g

Package width
132 mm

Quick installation guide
Yes

Screws included
Yes

Ports & interfaces

Expansion card standard
PCIe 3.0

Host interface
PCIe

Number of M.2 (M) slots
1

Output interface
M.2

System requirements

Linux operating systems supported
Yes

Weight & dimensions

Depth
102 mm

Height
18 mm

Weight
42 g

Width
40 mm

Description

Conceptronic EMRICK M.2 NVMe SSD PCIe Adapter. Host interface: PCIe, Output interface: M.2, Expansion card standard: PCIe 3.0. Country of origin: China. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10.... Width: 40 mm, Depth: 102 mm, Height: 18 mm. Package width: 132 mm, Package depth: 156 mm, Package height: 26 mm

Internal
Host interface: PCIe
Output interface: M.2
Supports PCIe Gen 3.0 x4
Supports M.2 PCIe NVMe SSD including 2230, 2242, 2260, and 2280 drives
Supports M Key and B+M Key M.2 SSD
Compatible with x4, x8, and x16 standard and low-profile PCI Express slots
Simple Plug and Play installation
NOT compatible with B Key M.2 PCI x2 SSD or B Key M.2 SATA SSD
