Synology DiskStation DS3622xs+ NAS Tower Ethernet LAN Black D-1531

Roll over image to zoom inClick to Open expanded view

Synology DiskStation DS3622xs+ NAS Tower Ethernet LAN Black D-1531

Name: Synology DiskStation DS3622xs+ NAS Tower Ethernet LAN Black D-1531
Brand: Synology
SKU: DS3622XS+

SKU: DS3622XS+

Log In to View Pricing

Synology DiskStation DS3622xs+, NAS, Tower, Intel® Xeon® D, D-1531, Black

hypertec

Product manual (Download)

Add to compare

Product Properties

Manufacturer
Synology

Warranty
5 Years

Drive
Without Drives

SKU
DS3622XS+

EAN
4711174724208

Bullet points

Point
16 GB DDR4 ECC, expandable to 48 GB

4,719 MB/s seq. read 260,691 4K random read IOPS

Six-core Intel Xeon

Triple in size to 36 drives with two DX1222 expansion units

Certificates

Certification
FCC CE BSMI VCCI RCM UKCA EAC KC UL

Design

Chassis type
Tower

Cooling type
Active

Fan diameter
12 cm

Fan diameter 2
12 cm

Number of fans
2 fan(s)

Product colour
Black

Logistics data

Harmonized System (HS) code
84714100

Memory

Internal memory type
DDR4

Maximum RAM supported
48 GB

Memory form factor
SO-DIMM

Memory Installed
16 GB

Memory slots
4

Network

Ethernet LAN
Yes

Ethernet LAN data rates
1000,10000 Mbit/s

Link aggregation
Yes

Supported network protocols
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Wake-on-LAN ready
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 40 °C

Storage temperature (T-T)
-20 - 60 °C

Packaging content

Cables included
AC, LAN (RJ-45)

Performance

Access Control List (ACL)
Yes

Backup function
Yes

Browser supported
Safari, Google Chrome, Firefox, Microsoft Edge

Device class
Home & Home Office

Multilingual support
Yes

Noise level
25 dB

Type
NAS

Web-based management
Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports
4

PCI Express x8 (Gen 3.x) slots
1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2

USB port
Yes

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Number of power supply units
1

Power consumption (HDD standby)
54.33 W

Power consumption (typical)
94.42 W

Power supply location
Built-in

Power supply unit (PSU) capacity
550 W

Processor

Conflict-Free processor
Yes

CPU configuration (max)
1

Number of Cores
6

Number of processors supported
1

Processor
D-1531

Processor boost frequency
2.7 GHz

Processor family
Intel® Xeon® D

Processor frequency
2.2 GHz

Processor manufacturer
Intel

Processor special features

Embedded options available
No

Enhanced Intel SpeedStep Technology
Yes

Execute Disable Bit
Yes

Idle States
Yes

Intel 64
Yes

Intel Enhanced Halt State
Yes

Intel Secure Key Technology version
1.00

Intel Trusted Execution Technology
Yes

Intel TSX-NI
Yes

Intel TSX-NI version
1.00

Intel Virtualization Technology (VT-x)
Yes

Intel Virtualization Technology for Directed I/O (VT-d)
Yes

Intel VT-x with Extended Page Tables (EPT)
Yes

Software

Operating system installed
DiskStation Manager

Server operating systems supported
Windows Server 2016, Windows Server 2019

Storage

Hot-swap drive bays
Yes

Installed storage drive type
No

Maximum supported storage capacity
200 TB

Number of storage drives supported
12

RAID levels
0, 1, 5, 6, 10, JBOD

RAID support
Yes

Storage drive sizes supported
2.5,3.5"

Storage drives installed
No

Supported file systems
BTRFS, Fat, HFS+, NTFS, ext3, ext4

Supported storage drive interfaces
Serial ATA, Serial ATA II, Serial ATA III

Supported storage drive types
HDD & SSD

Weight & dimensions

Depth
340 mm

Height
270 mm

Weight
9.8 kg

Width
300 mm

Description

Synology DiskStation DS3622xs+. Supported storage drive types: HDD & SSD, Supported storage drive interfaces: Serial ATA, Serial ATA II, Serial ATA III, Storage drive sizes supported: 2.5,3.5". Processor family: Intel® Xeon® D, Processor manufacturer: Intel, Processor model: D-1531. Internal memory: 16 GB, Internal memory type: DDR4, Maximum RAM supported: 48 GB. Ethernet LAN data rates: 1000,10000 Mbit/s, Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP,.... Chassis type: Tower, Cooling type: Active, Product colour: Black

Home & Home Office NAS Tower Black
DiskStation Manager
Number of storage drives supported: 12 HDD & SSD Serial ATA, Serial ATA II, Serial ATA III
Intel® Xeon® D D-1531 2.2 GHz
16 DDR4 Memory slots: 4 SO-DIMM
Ethernet LAN Wake-on-LAN ready
Cooling type: Active
550 W
Six-core Intel Xeon
4,719 MB/s seq. read 260,691 4K random read IOPS
16 GB DDR4 ECC, expandable to 48 GB
Triple in size to 36 drives with two DX1222 expansion units
