Synology DiskStation DS2422+ NAS/storage server Tower Ethernet LAN Black V1500B

Roll over image to zoom inClick to Open expanded view

Synology DiskStation DS2422+ NAS/storage server Tower Ethernet LAN Black V1500B

Name: Synology DiskStation DS2422+ NAS/storage server Tower Ethernet LAN Black V1500B
Brand: Synology
SKU: DS2422+

SKU: DS2422+

Log In to View Pricing

Synology DiskStation DS2422+, NAS, Tower, AMD Ryzen, V1500B, Black

Add to compare

Product Properties

Manufacturer
Synology

Warranty
3 Years

Drive
Without Drives

SKU
DS2422+

EAN
4711174723980

Bullet points

Point
2,201/1,383 MB/s sequential read read/write throughput

AMD Ryzen Quad-core 2.2 GHz

Easily add 10/25GbE and NVMe SSD cache

Expand to 24 bays with one DX1222 expansion unit

Certificates

Certification
FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL

Design

Chassis type
Tower

Cooling type
Active

Drive bay locking
Yes

Fan diameter
12 cm

Fan diameter 2
12 cm

Number of fans
2 fan(s)

Product colour
Black

Logistics data

Harmonized System (HS) code
84714100

Memory

ECC
Yes

Internal memory type
DDR4

Maximum RAM supported
32 GB

Memory form factor
SO-DIMM

Memory Installed
4 GB

Memory slots
2

Network

Ethernet LAN
Yes

Ethernet LAN data rates
1000 Mbit/s

Link aggregation
Yes

Supported network protocols
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Wake-on-LAN ready
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
-20 - 60 °C

Packaging content

Cables included
AC, LAN (RJ-45)

Performance

Access Control List (ACL)
Yes

Backup features
Cloud, iSCSI LUN

Backup function
Yes

Browser supported
Chrome, Firefox, Edge, Internet Explorer, Safari

Device class
Small & Medium Business

Multilingual support
Yes

Noise level
25 dB

Type
NAS

Web-based management
Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports
4

PCI Express x8 (Gen 3.x) slots
1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2

USB port
Yes

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Number of power supply units
1

Power consumption (HDD standby)
32.12 W

Power consumption (typical)
73.11 W

Power supply location
Built-in

Power supply unit (PSU) capacity
550 W

Processor

Number of Cores
4

Number of processors supported
1

Processor
V1500B

Processor family
AMD Ryzen

Processor frequency
2.2 GHz

Processor manufacturer
AMD

Software

Operating system installed
DiskStation Manager

Storage

Hot-swap drive bays
Yes

Installed storage drive type
No

Maximum supported storage capacity
108 TB

Number of storage drives supported
12

RAID levels
0, 5, 6, 10, JBOD

RAID support
Yes

Storage drive sizes supported
2.5,3.5"

Storage drives installed
No

Supported file systems
BTRFS, Fat, HFS+, NTFS, ext3, ext4

Supported storage drive interfaces
Serial ATA, Serial ATA II, Serial ATA III

Supported storage drive types
HDD & SSD

Technical details

Sustainability certificates
RoHS

Weight & dimensions

Depth
340 mm

Height
270 mm

Weight
9.5 kg

Width
300 mm

Description

Synology DiskStation DS2422+. Supported storage drive types: HDD & SSD, Supported storage drive interfaces: Serial ATA, Serial ATA II, Serial ATA III, Storage drive sizes supported: 2.5,3.5". Processor family: AMD Ryzen, Processor manufacturer: AMD, Processor model: V1500B. Internal memory: 4 GB, Internal memory type: DDR4, Maximum RAM supported: 32 GB. Ethernet LAN data rates: 1000 Mbit/s, Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV. Chassis type: Tower, Cooling type: Active, Product colour: Black

Small & Medium Business NAS Tower Black
DiskStation Manager
Number of storage drives supported: 12 HDD & SSD Serial ATA, Serial ATA II, Serial ATA III
AMD Ryzen V1500B 2.2 GHz
4 DDR4 Memory slots: 2 SO-DIMM ECC
Ethernet LAN Wake-on-LAN ready
Cooling type: Active
Backup features: Cloud, iSCSI LUN 550 W
AMD Ryzen Quad-core 2.2 GHz
2,201/1,383 MB/s sequential read read/write throughput
Easily add 10/25GbE and NVMe SSD cache
Expand to 24 bays with one DX1222 expansion unit
