Dataflex Viewlite plus monitor arm - rail 512

Name: Dataflex Viewlite plus monitor arm - rail 512
Brand: Dataflex
SKU: 58.512

SKU: 58.512

Dataflex Viewlite plus monitor arm - rail 512, 7 kg, 61 cm (24"), 75 x 75 mm, 100 x 100 mm, Height adjustment, Silver, White

hypertec

Generated PDF (Download)

Add to compare

Product Properties

Manufacturer
Dataflex

Warranty
5 Years

SKU
58.512

EAN
0805410585129

Bullet points

Point
40% of aluminium content is already recycled

Arm: swivel +90°/-90°

Comes with a rail mount

Dependent depth adjustment

Dynamic height adjustment range of 240 mm (9,4")

Fitted with a practical quick-release VESA system

INTEGRATED CABLE MANAGEMENT

Main components made of aluminium

Monitor rotation lock can be enabled

Monitor: tilt +90°/-55°, swivel +90°/-90°, rotate 360°

Swivel limiter pre-set to +90°/-90° or can be disabled

VESA MIS-D 75 x 75/100 x 100 mm compatible

Weight capacity min. 0 kg - max. 7 kg (0 - 15,4 lb) per monitor

Design

Housing material
Aluminium

Product colour
Silver, White

Ergonomics

Angle of rotation
360°

Cable management
Yes

Height adjustment
Yes

Height adjustment range
0 - 240 mm

Height adjustment type
Manual

Number of pivot points
2

Swivel angle range
-90 - 90°

Tilt angle range
-55 - 90°

Logistics data

Harmonized System (HS) code
85299097

Mounting

Maximum screen size
61 cm (24")

Maximum VESA mount
100 x 100 mm

Maximum weight capacity
7 kg

Minimum VESA mount
75 x 75 mm

Mounting type
Wall

Number of displays supported
1

Panel mounting interface
75 x 75,100 x 100 mm

Packaging content

Manual
Yes

Mounting kit
Yes

Weight & dimensions

Depth
375 mm

Package depth
153 mm

Package height
145 mm

Package weight
2.15 kg

Package width
477 mm

Width
112 mm

Description

Dataflex Viewlite plus monitor arm - rail 512. Maximum weight capacity: 7 kg, Maximum screen size: 61 cm (24"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Height adjustment, Swivel angle range: -90 - 90°, Tilt angle range: -55 - 90°. Product colour: Silver, White

Maximum weight capacity: 7 kg
Maximum screen size: 61 cm (24")
Number of displays supported: 1
Mounting type: Wall
Maximum VESA mount: 100 x 100 mm
Manual Height adjustment
Cable management
Aluminium Silver, White
Dynamic height adjustment range of 240 mm (9,4")
Dependent depth adjustment
Integrated cable management
Main components made of aluminium
40% of aluminium content is already recycled
VESA MIS-D 75 x 75/100 x 100 mm compatible
Monitor: tilt +90°/-55°, swivel +90°/-90°, rotate 360°
Arm: swivel +90°/-90°
Weight capacity min. 0 kg - max. 7 kg (0 - 15,4 lb) per monitor
Comes with a rail mount
Fitted with a practical quick-release VESA system
Monitor rotation lock can be enabled
Swivel limiter pre-set to +90°/-90° or can be disabled
