CyberPower OL10KERTHD uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W 10 AC outlet(s)

Roll over image to zoom inClick to Open expanded view

CyberPower OL10KERTHD uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W 10 AC outlet(s)

Name: CyberPower OL10KERTHD uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W 10 AC outlet(s)
Brand: CyberPower
SKU: OL10KERTHD

SKU: OL10KERTHD

Log In to View Pricing

CyberPower OL10KERTHD, Double-conversion (Online), 10 kVA, 10000 W, Pure sine, 200 V, 240 V

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
CyberPower

Warranty
2 Years

SKU
OL10KERTHD

EAN
4711027799025

Battery

Battery recharge time
4 h

Battery technology
Lead-Calcium (Pb-Ca)

Battery voltage
192 V

Hot-swap battery
Yes

Typical backup time at full load
2.4 min

Typical backup time at half load
8.3 min

Bullet points

Design

Built-in fan
Yes

Control type
Buttons

Display type
LCD

Form factor
Rackmount/Tower

Housing material
Metal

Product colour
Black

Rack capacity
4U

Features

Audible alarm(s)
Yes

Country of origin
China

Crest factor
3:1

ECO mode
Yes

Emergency Power Off (EPO)
Yes

EMI/RFI noise filtering
Yes

Heat dissipation
2044 BTU/h

Input frequency
50/60 Hz

Input operation voltage (max)
240 V

Input operation voltage (min)
200 V

Maximum current
55 A

Output frequency
50/60 Hz

Output operation voltage (max)
240 V

Output operation voltage (min)
200 V

Output power
10000 W

Output power capacity
10 kVA

Power factor
1

Surge energy rating
2430 J

Surge protection
Yes

Total Harmonic Distortion (THD) (linear load)
3%

Total Harmonic Distortion (THD) (non-linear load)
5%

UPS topology
Double-conversion (Online)

Waveform
Pure sine

Logistics data

Harmonized System (HS) code
8504408690

Operational conditions

Non-operating altitude
0 - 4500 m

Operating altitude
0 - 3000 m

Operating relative humidity (H-H)
0 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
0 - 95%

Storage temperature (T-T)
-5 - 45 °C

Other features

Battery type
RBP0159

Ports & interfaces

AC outlet types
C13 coupler, C19 coupler, Terminal

AC outlets quantity
10 AC outlet(s)

Power plug
Terminal

Serial interface
Yes

Serial ports quantity
1

USB 2.0 ports quantity
1

USB port
Yes

Technical details

Compliance certificates
CE, EAC, RCM, RoHS

Sustainability compliance
Yes

Weight & dimensions

Depth
720 mm

Height
173 mm

Package depth
890 mm

Package height
488 mm

Package weight
92 kg

Package width
590 mm

Weight
71.2 kg

Width
433 mm

Description

CyberPower OL10KERTHD. UPS topology: Double-conversion (Online), Output power capacity: 10 kVA, Output power: 10000 W. AC outlet types: C13 coupler, C19 coupler, Terminal, Power plug: Terminal, AC outlets quantity: 10 AC outlet(s). Battery technology: Lead-Calcium (Pb-Ca), Battery voltage: 192 V, Typical backup time at full load: 2.4 min. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Width: 433 mm, Depth: 720 mm, Height: 173 mm

Double-conversion (Online)
10 kVA 10000 W
Waveform: Pure sine
10 AC outlet(s)
Lead-Calcium (Pb-Ca) 192 V
Rackmount/Tower Black
Online (Double Conversion) UPS Topology
High Density Design
High Output Power Factor
Tiltable LCD Panel
Surge and Spike Protection
Controllable Outlet Groups
Battery Management Technology
Extended Battery Module (EBM)
Emergency Power Off (EPO) Port
PowerPanel Management Software
ECO Mode
Color LCD Panel
Quick Charging Technology
Automatically rotatable LCD
Critical/Non-critical Load Outlets
Generator Compatible
Hot-swappable Batteries
Smart Battery Management (SBM)
SNMP/HTTP Remote Management Capability
