• Bullet points

• Point
• 16 GB DDR4-SDRAM, 512 GB SSD
  Intel Xeon W-2225 (4.1 GHz)
  Windows 10 Pro for Workstations 64-bit

• Certificates

• Certification
• GreenGuard, ISV

• Design

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Chassis type
• Tower

• Number of 2.5" bays
• 4

• Number of 3.5" bays
• 4

• Placement supported
• Vertical

• Product colour
• Black

• Volume
• 25 L

• Expansion slots

• PCI Express x16 (Gen 3.x) slots
• 2

• PCI Express x4 (Gen 3.x) slots
• 1

• PCI Express x8 (Gen 3.x) slots
• 1

• Filters

• Machinecategory
• Workstation

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• On-board graphics card
• No

• On-board graphics card model
• Not available

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2933 MHz

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 1 x 16 GB

• Memory Slot Support
• 128 GB

• Memory slots
• 4x DIMM

• Network

• Bluetooth
• No

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wake-on-LAN ready
• Yes

• Wi-Fi
• No

• Operational conditions

• Non-operating altitude
• -15.2 - 10668 m

• Operating altitude
• -15.2 - 3048 m

• Operating relative humidity (H-H)
• 20 - 80%

• Operating temperature (T-T)
• 10 - 35 °C

• Storage relative humidity (H-H)
• 10 - 90%

• Storage temperature (T-T)
• -40 - 60 °C

• Packaging content

• Display included
• No

• Keyboard included
• Yes

• Keyboard included on selected markets only
• Yes

• Keyboard layout
• QWERTY

• Mouse included
• Yes

• Mouse included on selected markets only
• Yes

• Performance

• Audio chip
• Realtek ALC662

• Audio system
• High Definition Audio

• Compatible processor series
• Intel Xeon W

• Market positioning
• Business

• Motherboard chipset
• Intel® C422

• Password protection
• Yes

• Password protection type
• Power on, Supervisor

• Product type
• Workstation

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 1

• Line-in
• Yes

• Line-out
• Yes

• Microphone in
• Yes

• PS/2 ports quantity
• 2

• USB 2.0 ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 6

• Power

• 80 PLUS certification
• 80 PLUS Platinum

• Power supply
• 500 W

• Power supply input frequency
• 50 - 60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Maximum internal memory supported by processor
• 1.02 TB

• Maximum number of PCI Express lanes
• 48

• Memory bandwidth supported by processor (max)
• 93.85 GB/s

• Memory clock speeds supported by processor
• 2933 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 4

• Number of processors installed
• 1

• PCI Express configurations
• 1x4, 1x8, 1x16

• PCI Express slots version
• 3.0

• Processor
• W-2225

• Processor boost frequency
• 4.6 GHz

• Processor cache
• 8.25 MB

• Processor cache type
• Smart Cache

• Processor codename
• Cascade Lake

• Processor family
• Intel Xeon W

• Processor frequency
• 4.1 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• LGA 2066 (Socket R4)

• Processor threads
• 8

• Tcase
• 61 °C

• Thermal Design Power (TDP)
• 105 W

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Demand Based Switching
• Yes

• Intel Flex Memory Access
• No

• Intel Software Guard Extensions (Intel SGX)
• No

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor ARK ID
• 198610

• Processor package size
• 45 x 52.5 mm

• Scalability
• 1S

• Supported instruction sets
• SSE4.2, AVX, AVX 2.0, AVX-512

• Thermal Monitoring Technologies
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro for Workstations

• Operating system language
• English

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD

• Number of SSDs installed
• 1

• NVMe
• Yes

• Optical drive type
• DVD±RW

• SSD capacity
• 512 GB

• SSD form factor
• M.2

• SSD interface
• NVMe, PCI Express

• Storage Capacity
• 512 GB

• Storage type
• SSD

• Total SSDs capacity
• 512 GB

• Sustainability

• Sustainability certificates
• RoHS, EPEAT Silver, ENERGY STAR

• Weight & dimensions

• Depth
• 426 mm

• Height
• 376 mm

• Weight
• 14.5 kg

• Width
• 175 mm
