• Audio

• Audio chip
• Realtek ALC3246

• Audio system
• MaxxAudio Pro

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Speaker power
• 2 W

• Speakers manufacturer
• Waves

• Battery

• Battery capacity
• 56 Wh

• Battery technology
• Lithium Polymer (LiPo)

• Battery voltage
• 15.2 V

• Number of battery cells
• 4

• Camera

• Front camera
• Yes

• Front camera HD type
• HD

• Front camera resolution
• 1280 x 720 pixels

• Front camera resolution (numeric)
• 0.92 MP

• Front camera signal format
• 720p

• Video capturing speed
• 30 fps

• Design

• Form factor
• Clamshell

• Market positioning
• Business

• Product colour
• Black

• Product type
• Laptop

• Display

• Contrast ratio (typical)
• 400:1

• Display brightness
• 220 cd/m²

• Display surface
• Matt

• HD type
• Full HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Pixel density
• 141 ppi

• Pixel pitch
• 0.179 x 0.179 mm

• Screen Resolution
• 1920 x 1080 pixels

• Screen Size
• 39.6 cm (15.6")

• Touchscreen
• No

• Filters

• Machinecategory
• Notebook

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• Maximum on-board graphics card memory
• 32 GB

• Number of discrete graphics cards supported
• 1

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 300 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1000 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0x5916

• On-board graphics card model
• Intel® HD Graphics 620

• On-board graphics card OpenGL version
• 4.4

• Keyboard

• Full-size keyboard
• Yes

• Keyboard backlit
• Yes

• Numeric keypad
• Yes

• Pointing device
• Touchpad

• Windows keys
• Yes

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2133 MHz

• Memory form factor
• SO-DIMM

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 1 x 8 GB

• Memory Slot Support
• 32 GB

• Memory slots
• 2x SO-DIMM

• Network

• Bluetooth
• Yes

• Bluetooth Low Energy (BLE)
• Yes

• Bluetooth version
• 4.1

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• MIMO
• Yes

• MIMO type
• Multi User MIMO

• Top Wi-Fi standard
• Wi-Fi 5 (802.11ac)

• Wi-Fi
• Yes

• Wi-Fi data rate (max)
• 867 Mbit/s

• Wi-Fi standards
• 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

• Operational conditions

• Non-operating altitude
• 0 - 10668 m

• Operating altitude
• 0 - 3048 m

• Operating relative humidity (H-H)
• 10 - 90%

• Operating temperature (T-T)
• 0 - 35 °C

• Storage relative humidity (H-H)
• 0 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Other features

• AC adapter included
• Yes

• Maximum internal memory (64-bit)
• 32 GB

• USB Power Delivery revision
• 2.0

• Packaging content

• Manual
• Yes

• Power cord included
• Yes

• Warranty card
• Yes

• Ports & interfaces

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• HDMI version
• 1.4

• Number of USB ports with PowerShare support
• 1

• PowerShare
• Yes

• USB 2.0 ports quantity
• 1

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 1

• USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
• 1

• USB Power Delivery
• Yes

• USB Type-C DisplayPort Alternate Mode
• Yes

• VGA (D-Sub) ports quantity
• 1

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter output current
• 3.34 A

• AC adapter output voltage
• 19.5 V

• AC adapter power
• 65 W

• Processor

• Bus type
• OPI

• Configurable TDP-down
• 7.5 W

• Configurable TDP-down frequency
• 0.8 GHz

• Configurable TDP-up
• 25 W

• Configurable TDP-up frequency
• 2.7 GHz

• ECC supported by processor
• No

• Maximum number of PCI Express lanes
• 12

• Number of Cores
• 2

• PCI Express configurations
• 1x2+2x1, 1x4, 2x2, 4x1

• PCI Express slots version
• 3.0

• Processor
• i5-7200U

• Processor boost frequency
• 3.1 GHz

• Processor cache
• 3 MB

• Processor cache type
• Smart Cache

• Processor codename
• Kaby Lake

• Processor family
• Intel® Core™ i5

• Processor frequency
• 2.5 GHz

• Processor generation
• 7th gen Intel® Core™ i5

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• BGA 1356

• Processor threads
• 4

• Stepping
• H0

• System bus rate
• 4 GT/s

• Thermal Design Power (TDP)
• 15 W

• Tjunction
• 100 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 14 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Smart Response Technology version
• 1.00

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• No

• Intel Stable Image Platform Program (SIPP) version
• 0.00

• Intel Trusted Execution Technology
• No

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• Yes

• Intel® Smart Response Technology
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 95443

• Processor code
• SR2ZU

• Processor package size
• 42 x 24 mm

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Cable lock slot type
• Noble

• Password protection
• Yes

• Password protection type
• BIOS, User

• Trusted Platform Module (TPM)
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Operating system language
• English

• Trial software
• Microsoft Office, McAfee

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD, SDHC, SDXC

• Number of SSDs installed
• 1

• Optical drive type
• No

• SSD capacity
• 256 GB

• SSD form factor
• M.2

• SSD interface
• SATA III

• Storage Capacity
• 256 GB

• Storage type
• SSD

• Weight & dimensions

• Depth
• 258 mm

• Height
• 22.7 mm

• Weight
• 2.02 kg

• Width
• 380 mm
